DM Series Digital Matrix Processors
Serial Interface & Control Commands (cont'd)
address is wildcarded, then the data type is an array of
integer of size 16. In this case the value 9999 may be
used in an update to indicate that a particular input
delay is to remain unchanged by the command.
Examples:
REQUEST
QUERY indel(1)?
QUERY indel(*)?
UPDATE indel(15)=30
UPDATE
indel(*)={12,0,0,...,8,9999,9999}

ingn (input gain)

This command may be used as a query to read the
input channel gain, or as an update to set the gain. The
input channel is specified by using the address syntax.
Addresses must be in the range 1 to 16. The data type
is integer, in the range -10 to +60, representing the gain
in dB. If the channel address is wildcarded, then the
data type is an array of integer of size 16. In this case
the value 99 may be used in an update to indicate that a
particular input gain is to remain unchanged by the
command.
Examples:
REQUEST
QUERY ingn(1)?
QUERY ingn(*)?
UPDATE ingn(15)=30
UPDATE
ingn(*)={40,40,50,...,0,99,99}

iniv (input phase invert)

This command may be used as a query to read the
input channel phase invert status, or as an update to set
the status. The input channel is specified by using the
address syntax. Addresses must be in the range 1 to 16.
The data type is integer, either "1" meaning that the
input has the audio phase inverted (shifted by 180
degrees), or "0" meaning that it is not. If the channel
address is wildcarded, then the data type is an array of
integer of size 16. In this case the value 99 may be used
in an update to indicate that a particular input invert
state is to remain unchanged by the command.
Examples:
REQUEST
QUERY iniv(9)?
QUERY iniv(*)?
UPDATE iniv(2)=1
UPDATE
iniv(*)={0,0,1,...,99,99,99}
34
RESPONSE
OK 42
OK {0,40,0,...,0,0,0}
OK
OK
RESPONSE
OK 42
OK {40,40,50,...,0,0,0}
OK
OK
RESPONSE
OK 0
OK {0,1,0,...,0,0,0}
OK
OK

inlb (input channel label)

This command may be used as a query to read the
input channel text label, or as an update to set the label.
The input channel is specified by using the address
syntax. Addresses must be in the range 1 to 16. The
data type is string, with a limit of 15 characters.
Examples:
REQUEST
QUERY inlb(1)?
UPDATE inlb(12)="#3 West"

inlv (input level)

This command may be used as a query to read the
input channel level. The input channel is specified by
using the address syntax. Addresses must be in the
range 1 to 16. The data type is integer, in the range -70
to +20, representing the RMS audio level in dBu as
measured AFTER the input preamplifier. If the channel
address is wildcarded, then the data type is an array of
integer of size 16.
Examples:
REQUEST RESPONSE
QUERY inlv(1)? OK -23
QUERY inlv(*)? OK {-2,4,-10,...,-53,-71,-60}

inmt (input mute)

This command may be used as a query to read the
input channel mute status, or as an update to set the
status. The input channel is specified by using the
address syntax. Addresses must be in the range 1 to 16.
The data type is integer, either "1" meaning that the
input is muted, or "0" meaning that it is not. If the
channel address is wildcarded, then the data type is an
array of integer of size 16. In this case the value 99 may
be used in an update to indicate that a particular input
mute is to remain unchanged by the command.
Examples:
REQUEST
QUERY inmt(9)?
QUERY inmt(*)?
UPDATE inmt(2)=0
UPDATE
inmt(*)={0,0,0,...,99,99,0}
RESPONSE
OK "Chairman"
OK
RESPONSE
OK 1
OK {0,0,0,...,0,1,0}
OK
OK
