Atlantic AOYA 30 LBTL Installation And Commissioning Instructions

Water/air heat pump with integrated fuel oil burner, single phase or three phase split, 2 services
Hide thumbs Also See for AOYA 30 LBTL:
Table of Contents

Advertisement

Quick Links

alféa hybrid duo
Water/air heat pump
with integrated fuel oil burner,
single phase or three phase
split, 2 services
Outdoor unit
AOYA 30 LBTL
AOYA 45 LBTL
AOY 54 LJBYL
WOYK112LCT
WOYK140LCT
WOYK160LCT
10
11
Hydraulic module
024101
Document n° 1440-13 ~ 20/12/2012
Document n° 1440-11 ~ 29/08/2012
FR
ES
PT
IT
FI
SE
Installation and
commissioning
instructions
for professionals
To be kept by the user
for future reference
atlantic-comfort.com
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AOYA 30 LBTL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atlantic AOYA 30 LBTL

Summary of Contents for Atlantic AOYA 30 LBTL

  • Page 1 Document n° 1440-13 ~ 20/12/2012 Water/air heat pump with integrated fuel oil burner, single phase or three phase split, 2 services Outdoor unit Hydraulic module AOYA 30 LBTL 024101 AOYA 45 LBTL AOY 54 LJBYL WOYK112LCT WOYK140LCT WOYK160LCT Installation and...

  • Page 2: Table Of Contents

    Heat pump alfea hybrid duo Thank you for buying this product. Sommuary Presentation of the equipment ......4 Packaging .
  • Page 3 Heat pump alfea hybrid duo The following are required for the installation of this appliance: - a heating engineer. Regulation ........38 .

  • Page 4: Presentation Of The Equipment

    Heat pump alfea hybrid duo 1 Presentation of the equipment Packaging Pairing table Heat pump Outdoor unit Hydraulic module hybrid duo Heat pump Outdoor unit Hydraulic module hybrid duo Model Model Export code Export code Ref. Ref. Code Code Ref. Ref.
  • Page 5 Heat pump alfea hybrid duo Denomination of model ..alféa hybrid duo ..10 ..13 ..16 ..11 tri ..14 tri ..16 tri .
  • Page 6 Heat pump alfea hybrid duo hybrid duo 10 model Bottom view 3/8" 5/8" Front view Side view Top view hybrid duo 16 model Bottom view 1290 3/8" 5/8" Front view Side view Top view...
  • Page 7 Heat pump alfea hybrid duo model hybrid duo 16 tri Drain hole Bottom view 1290 Hydraulic unit 1015 Hydraulic module male 1682 1711 Rear view Side view Front view...
  • Page 8 Heat pump alfea hybrid duo 43907 10000 2490 1000 ° C 32500 30000 27500 25000 22500 1 mbar = 10 mmCE = 100 Pa mbar 20000 17500 15000 12500 10000 7500 5000 2500 °C m /h 10000 1000 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130 Temperature °C...
  • Page 9 Heat pump alfea hybrid duo Description model hybrid duo 10 operation hybrid duo 16 tri WO*K1**LCT liquid.
  • Page 10 Heat pump alfea hybrid duo pump Control panel 16. Manual drain tap Burner 12. heating circulation pump...

  • Page 11: Operating Principle

    Heat pump alfea hybrid duo Operating principle Regulation functions 10 or 16 automatic. pump. 9 or 15 Protection functions page 30 HEAT PUMP 4 kW Heat produced 20 °C Air energy COP 4 Heat pump 1 kW Electrical energy consumed...
  • Page 12 Heat pump alfea hybrid duo Operating principle of the domestic hot water °C through the day. °C 10 l/min DHW timer programme. 12,5 l/min 15 l/min Fan coil units with integrated regulation...

  • Page 13: Installation

    Heat pump alfea hybrid duo 2 Installation Statutory conditions 2.3.3 Containment of refrigerant circuits for installation and servicing the heat pump. It’s necessary to ensure correct containment Use of new fuels objects into the compressor oil would lead to systematic exclusion of warranty. domestic fuel containing FAME FAME Unpacking and reserves...

  • Page 14: Fitting The Outdoor Unit

    Heat pump alfea hybrid duo Installing the outdoor unit 2.5.1 Installation precautions The outdoor unit must only be installed large apertures on all 4 sides and respect the H > 50 mm *In regions where it snows often, (H) must be greater than Dans les régions fréquemment enneigées, the average thickness of the snow (H) doit être supérieur à...
  • Page 15 Heat pump alfea hybrid duo 2.5.3 Connection of the condensate evacuation pipe If installed in a region where the temperature may pipe must have a resistance tracer to avoid it icing over. The resistance trace must heat not just the evacuation pipe but also the bottom of the condensate drip tray of the appliance.
  • Page 16 Heat pump alfea hybrid duo 150 mm Minimum 1000 mm 1000 mm ou plus ou plus Minimum 1500 mm 1000 mm 300 mm 500 mm Max. 500 mm Max. 500 mm 500 mm 300 mm 1500 mm ou plus Minimum 1500 mm ou plus Minimum 1500 mm...
  • Page 17 Heat pump alfea hybrid duo Installing the hydraulic module 2.6.1 Requirements of installation space 300 mm 50 cm 100 cm The warranty on the heater will not cover any minimum installation of the appliance in a chlorine rich 150 mm* or any other corrosive vapours.

  • Page 18: Connection Pipe

    Heat pump alfea hybrid duo 2.6.3 Connection pipe Brazing on the refrigerating circuit than 30 Pa. appliance. Refrigerating connections R410A. 2.7.1 Rules and precautions circuit. Minimum necessary tools Manifold Flaring tool. Provision on using tools that have been in The manufacturer declines any liability with regard to the guarantee if the above instructions Flare are not observed.

  • Page 19: Flaring

    Heat pump alfea hybrid duo 2.7.2 Refrigerating connections 2.7.5 The small tube must always be connected hydraulic module using only copper connections before the large one. Pay special attention to the position of the tube aligned with its connector to avoid damaging the thread.
  • Page 20 Heat pump alfea hybrid duo liquid Outdoor unit Hydraulic Module Unité module hydraulique extérieure Vanne “liquide” Liquid valve Écrou flare Flare nut "Liquid" refrigerating Liaison frigorifique “liquide” connection diameter D2 diamètre D2 Flare nut Écrou flare Gas valve Vanne “gaz” Flare nut Écrou flare Flare nut...
  • Page 21 Heat pump alfea hybrid duo Commissioning of the refrigerating gas installation This operation is reserved for installers familiar Method 3 empty with the legislation for handling refrigerants. Manifold Creating a vacuum with a vacuum pump is refrigerant other than a HFC. ANNEX 1 Remove the refrigerant circuit caps only when Manometer kit...
  • Page 22 Heat pump alfea hybrid duo First seal test Refrigeration connexion Plug (A) Schrader Manifold. 3-way valve Manifold Hex / Allen key of 4 mm Load orifice Azote High Haute Plug (B) 10 bars max. Service hose (blue) pression during 30 mn mini. fitted with valve push-button 30 mn mini Liaison...

  • Page 23: Additional Charge

    Heat pump alfea hybrid duo model hybrid duo 10 single phase 40 g of R410A per extra m 15 m 25 m Additional charge none 400 g model hybrid duo 13 single phase 50 g of R410A per extra m 15 m 25 m Additional load...

  • Page 24: Hydraulic Connection

    Heat pump alfea hybrid duo 2.8.4 Hydraulic connection in the outdoor unit 2.9.1 General Only for the three phase models hydraulic module. hydraulic module. glycol. DIP SW LED1 LED2...
  • Page 25 Heat pump alfea hybrid duo 2.9.2 Connection to the domestic circuit leading to the drain. inlet. 2.9.3 Connection to a fan coil unit circuit 2.9.4 Rinsing the installation CAR: R1: Heating circuit Male...
  • Page 26 Heat pump alfea hybrid duo 2.9.5 Filling and draining the installation 2.10 Connection of the fuel supply Compulsory! Fill and pressurise the domestic The warranty of the appliance will not apply if this procedure is not respected. page hybrid duo 10/11 hybrid duo 10/11 hybrid duo 13/14 hybrid duo 13/14...
  • Page 27 Heat pump alfea hybrid duo 2.11 Electrical connections 2.11.1 Characteristics of the electrical power supply Warning! contract. the outdoor unit 2.11.2 General remarks on the electrical connections Connection to the spring terminal blocks: Connection to the connectors: connection.
  • Page 28 Heat pump alfea hybrid duo 2.11.3 Overall view of the electrical connections Electrical panel 2.11.4 Cross section of the cable and protection rating Power supply of the outdoor unit: 3910 W 3910 W 20 A 20 A 4600 W 4600 W 25 A 25 A 5980 W...
  • Page 29 Heat pump alfea hybrid duo 2.11.5 Electrical connections on outdoor unit side for single phase model Te r m i n a l and hydraulic module Déposer la façade (2 vis) Attach the cables so that they are not in contact Attachment plate Plaque de fixation Isolant (joint)
  • Page 30 Heat pump alfea hybrid duo 2.11.6 Electrical connections on the outdoor unit side for the three phase model clamp Terminal panel. Side Rear Terminal 2 3 L1 L2 L3 N INDOOR UNIT POWER General electrical the outdoor unit and Front hydraulic module...
  • Page 31 Heat pump alfea hybrid duo 2.11.7 Electrical connections on the hydraulic module side Grommet Heat pump regulator Contract with the energy supplier Inter-connection between the outdoor unit and the hydraulic module: and 8. During the Second heating circuit circuit hydraulic kit.
  • Page 32 Heat pump alfea hybrid duo Electrical and hydraulic module 230 V Outdoor unit Hydraulic module Outdoor unit 1 2 3 L1 L2 L3 N L1 L2 L3 N Electrical 400 V Hydraulic module and hydraulic module...
  • Page 33 Heat pump alfea hybrid duo M B9 CL- CL+ CL- CL+ CL- CL+ Outdoor Central Radio central circuit 1 or 2 circuit 2 or 1...
  • Page 34 Heat pump alfea hybrid duo 2.12 Outdoor sensor 2.13 Ambient sensor optional. in the morning. Installation equipped with two ambient sensors Installation equipped with a radio central ambient...
  • Page 35 Heat pump alfea hybrid duo 2.14 heating: It is essential to set the parameters 741 page 42 and/or page 44). page 40 Start/Stop...
  • Page 36 Heat pump alfea hybrid duo 2.15 Adjusting the burner 2.16 of the ambient sensor GPH and angle kg/h 2.30 2.15.1 Setting the electrodes default in zone 1. 2.15.2 Setting the combustion air circuit 2.17 Français...
  • Page 37 Heat pump alfea hybrid duo...

  • Page 38: Regulation

    Heat pump alfea hybrid duo 3 Regulation Auto Auto RESET Ref. Functions Selecting the DHW operation Start Stop Start Marche Manual start button Stop Arrêt Auto Selecting the heating operation Permanent reduced temperature. page 63 page 63 Selecting the cooling mode Do not use during normal operation.
  • Page 39 Heat pump alfea hybrid duo Auto °C Ref. Functions Selecting the heating operation Auto Permanent reduced temperature.

  • Page 40: Water Logic

    Heat pump alfea hybrid duo Water logic 3.3.1 Manual setting temperature.
  • Page 41 Heat pump alfea hybrid duo 2,75 ° C High and 2,25 medium temperature radiator 1,75 Burner operation 1,25 temperature radiator 0,75 Heat pump operation alone 0,25 ° C Water logic +4,5 -4,5 Outdoor temperature °C Good & Good Cold & Cold &...

  • Page 42: General

    Heat pump alfea hybrid duo Regulation parameters 3.4.1 General 3.4.2 Setting the parameters U I and S. ESC. Time and date Hour 1...24 h Day/month 0...60 min heating circuit1 timer Year programme Time and date Day/month heating circuit1 timer Year programme 01.01...31.12 time...
  • Page 43 Heat pump alfea hybrid duo Common with heating independent circuit1 Common with heating circuit1 Mon-Sun 10 min 06:00 10 min 22:00 10 min --:-- 10 min --:-- 10 min --:-- 10 min --:-- Mon-Sun 10 min 06:00 10 min 22:00 10 min --:-- 10 min...
  • Page 44 Heat pump alfea hybrid duo timer programme 5/Cooling Period 1 to 8 Period 1 Antifreeze protection Period 1 to 8 Period 1 Antifreeze protection 0.5°C 20°C 0.5°C 18°C 0.5°C 8°C 20°C... 35°C 1°C 28°C 0.1... 4 0.02 0.5°C Stop | Start Stop Warning! 8°C...
  • Page 45 Heat pump alfea hybrid duo 0... 360 min 10 min 120 min 1°C 1°C -5°C 0... 50°C 1°C 240 s Stop Functional heating Manual 0... 95°C 1°C 25°C Current drying day 0... 32 0... 32 Protection mode heating Respect the standards and values of the building constructor! Correct operation of this function is only possible with a correct interrupted earlier by setting to "Stop".
  • Page 46 Heat pump alfea hybrid duo 1010 0.5°C 20°C 1012 0.5°C 18°C 1014 0.5°C 8°C 1016 20... 35°C 1°C 28°C 1020 0.1... 4 0.02 1021 0.5°C 1026 Stop/Start Stop Warning! 1030 8... 30°C 0.5°C 18°C 1032 Daily heating limit 1°C -3°C 1040 8...
  • Page 47 Heat pump alfea hybrid duo 1200 Protection mode 1610 65°C 1612 8°C... 40°C 1620 24h/day Timer Heating circuit timer prog. programme Timer programme 4/DHW 4/DHW Timer prog. 4/DHW and THC 24h/day Heating circuit timer prog. Timer programme 4/DHW Timer prog. 4/DHW and THC* 1640 Stop Stop...
  • Page 48 Heat pump alfea hybrid duo 2910 1°C 2920 Liberated 3700 0.5°C 2°C 3705 0... 120 min 1 min 20 min 3720 0... 120°C. min 1°C. min 50°C. min 3723 1... 120 min 1 min 10 min DHW tank 5020 0... 30°C 1°C 18°C 5024...
  • Page 49 Heat pump alfea hybrid duo Error 6711 6740 Initial alarm T° heating circuit1 10 min 6741 Initial alarm T° heating circuit2 10 min 6745 DHW load alarm 6746 Initial cold alarm T° 1 10 min 6800 6802 6804 6806 6808 6810 6812 6814...
  • Page 50 Heat pump alfea hybrid duo Test of inputs/outputs 7700 Open Heating circuit 1 7710 7711 0... 10 Volt 7720 7721 Digital output DO1 Heating Heating operation operation 7722 Digital output DO2 Stop 7730 7820 7823 7824 7830 7831 7832 7833 7841 Open 7846...
  • Page 51 Heat pump alfea hybrid duo 8056 8058 8060 8062 8064 8066 8068 Diagnosis of generator 8402 Stop 8403 Stop 8406 Stop 8410 Heat pump return temperature 0... 140°C 8412 0... 140°C 8413 8425 8454 0... 2730 h 8455 Heat pump counter locking 0...
  • Page 52 Heat pump alfea hybrid duo 8756 0... 140°C 8760 Heating circuit2 pump Stop 8761 Stop 8762 Stop 8770 0... 50°C 20°C 20°C 8773 Start temperature 2 0... 140°C 50°C 50°C 8820 DHW circulation pump Stop 8821 Stop 8830 DHW temperature 0...
  • Page 53 Heat pump alfea hybrid duo...
  • Page 54 Heat pump alfea hybrid duo circuit kit. pool kit. Pre-setting 13 1 heating circuit. page 54 Pre-setting 14 page 55...
  • Page 55 Heat pump alfea hybrid duo Parameter 5700 page 54 page 55 circuit kit. 4.1.1 Hydraulic connections 4.1.3 Regulation parameters 5700. circuit kit. 1610 to 1661 circuit 1 heating circuit kit. line 720. 4.1.2 Electrical connections 2 heating circuits line 720 line 1020 hydraulic module.
  • Page 56 Heat pump alfea hybrid duo Refer to the detailed 1 heating circuit. instructions page 53 Hydraulic principle diagram Circuit 1 Overall view of the electrical connections Circuit 1...
  • Page 57 Heat pump alfea hybrid duo Refer to the detailed 2 heating circuits. instructions page 53 Hydraulic principle diagram Circuit 2 SDp2 Circuit 1 Overall view of the electrical connections Circuit 2 SDp2 Circuit 1 circuit kit SDp2 circuit regulator heating circuit2 circulation pump...

  • Page 58: Electrical Wiring Diagrams

    CN700 TM302 TM301 CN801 TM600 CN110 L2 L1 TM601 TM303 TM305 Coil W19 W3 TM102 W21 W9 CN100 TM304 TM101 Electrical AOYA 30 LBTL and hydraulic module BK Black BU Blue Green GY Grey OG Orange RD Red WH White...
  • Page 59 Heat pump alfea hybrid duo Outdoor R(R) 4 channel S(S) C(T) Fan 1 module Terminal Coil Fan 2 Electronic regulator Filter AOYA 45 LBTL BK Black BU Blue Terminal Green GY Grey OG Orange RD Red WH White and hydraulic module...
  • Page 60 Heat pump alfea hybrid duo BK Black BU Blue Green GY Grey OG Orange RD Red WH White Connector 4 channel Fan 1 module Coil Fan 2 Terminal Electronic regulator Noir Relay Filter Terminal AOY 54 LJBYL Electrical and hydraulic module...
  • Page 61 Heat pump alfea hybrid duo Re-injection pressure regulator coil Re-injection coil temp. sensor regulator. temp. sensor Evaporator atmosphere Temp. sensor. radiator Temp. sensor. Temp. sensor. Evaporator output Compressor Temp. sensor. Temp. sensor. Inverter radiator Temp. sensor. Compressor Filter Fan reactor 4 channel valve regulator coil...
  • Page 62 Heat pump alfea hybrid duo Burner Heating circulation pump Start/Stop Burner on LED Timed relay...

  • Page 63: Servicing And Troubleshooting

    Heat pump alfea hybrid duo 6 Servicing and troubleshooting Display information Servicing of the installation 6.2.1 Servicing of the heat exchanger page 63 Current drying day panel. 8006 8022 ceramic door protection. 8003 8011 8000 8001 Tighten the door locking screw moderately. 8004 Outdoor temperature.
  • Page 64 Heat pump alfea hybrid duo 6.2.2 Servicing the burner 6.2.3 Servicing the tank in the tank. alternately. the pocket. 6.2.4 Servicing the chimney 6.2.5 Servicing the safety appliances...
  • Page 65 Heat pump alfea hybrid duo Faults 6.3.1 Display on the hydraulic module automatically. Hydraulic module Error on outdoor unit (during a start phase, see § "Commissioning"). Hydraulic module Permanently lit Stop...
  • Page 66 Heat pump alfea hybrid duo 6.3.2 Faults displayed on the outdoor unit single phase model Permanently lit Drained. Permanently lit...
  • Page 67 Heat pump alfea hybrid duo 6.3.3 Faults displayed on the outdoor unit three phase model ERROR Terminal ERROR Error on P.F.C. Hydraulic module anomaly.

  • Page 68: Values To Be Given To The User

    7 Values to be given to the user Date of commissionning: atlantic-comfort.com www.atlantic.fr Société Industrielle de Chauffage SATC - BP 64 - 59660 MERVILLE - FRANCE Contact details of your heating engineer or After Sales service.

This manual is also suitable for:

Aoya 45 lbtlWoyk160lctAoy 54 ljbyl024101Alfea hybrid duo 10Alfea hybrid duo 13 ... Show all

Table of Contents
