Atlantic alféa extensa AOYA 18 LALL Installation And Operating Manual

Heat pump air/water split 1 service
Hide thumbs Also See for alféa extensa AOYA 18 LALL:

Advertisement

Table of Contents

alféa extensa
Heat pump air/water
split 1 service
Outdoor unit
AOYA 18 LALL
AOYA 30 LBTL
AOYA 36 LBTL
AOYA 45 LBTL
AOYA 54 LJBYL
Hydraulic unit
023141
023155
Document n° 1455-10 ~ 04/02/2013
FR
NL
DE
EN
ES
PT
PL
PT
Installation and
operating manual
intended for professionals
To be saved for
future consultation
atlantic-comfort.com
IT
PT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the alféa extensa AOYA 18 LALL and is the answer not in the manual?

Questions and answers

Related Manuals for Atlantic alféa extensa AOYA 18 LALL

Summary of Contents for Atlantic alféa extensa AOYA 18 LALL

  • Page 1 Heat pump air/water split 1 service Outdoor unit Hydraulic unit AOYA 18 LALL 023141 AOYA 30 LBTL 023155 AOYA 36 LBTL AOYA 45 LBTL AOYA 54 LJBYL Installation and operating manual intended for professionals To be saved for future consultation atlantic-comfort.com...
  • Page 2 capacity for handling refrigerants. Contents Description of the unit ......4 Package .

  • Page 3: Table Of Contents

    Regulation system ....... 32 ....36 .
  • Page 4 Packing list Heat pump (HP) Outdoor unit Hydraulic unit Model Code Model Code Model Code 023155 023141 700730 023155 700736 023141 522659 AOY54LJBYL 700054 Optional equipment Scope of application 2nd circuit kit Regulation extension kit DHW kit Boiler connection kit Electrical back-ups kit Room thermostat T37 Room thermostat T55...
  • Page 5 Designation model ..alféa extensa . . . 5 ..6 ..8 ..10 ..13..16 Nominal heating performances (outdoor temperature/ initial temperature) Heat output +7 °C / +35 °C - Floor heating system .
  • Page 6 Outside unit, Model extensa 5 & extensa 6 Overflow hole (Ø 20) 4 Holes Ø 10) Sight of lower part 1/4” 1/4” 1/2” 5/8” Front view Side view Top view Outside unit, Model extensa 8 & extensa 10 Overflow hole (Ø 20) Holes Ø...
  • Page 7 Outside unit, Model extensa 13 & extensa 16 Overflow hole (Ø 20) Holes Ø 10) Sight of lower part 1290 3/8” 5/8” Front view Side view Top view Dimensions in mm Hydraulic module Front view Side view Dimensions in mm...
  • Page 8 1 mbar = 10 mmCE = 100 Pa mbar 43907 ext. in 10000 2490 1000 ° C m /h 32500 1 mbar = 10 mmCE = 100 Pa 30000 mbar 27500 ext. in 25000 22500 20000 17500 15000 12500 10000 7500 5000 2500...
  • Page 9 Descriptif Model extensa 5 & extensa 6 Model extensa 13 & extensa 16 Model extensa 8 & extensa 10 Legend : Outside unit components...
  • Page 10 Legend : 8 - Heating return. 9 - Drain valve. 10 - Safety valve. 11 - Manometer. 12 - Manual drainer. 13 - 14 - Condenser. Side view Front view Hydraulic unit components Operating principle Regulation functions Protection functions...
  • Page 11 4 kW 20 °C Heat produced Energy from the air COP 4 1 kW Electrical energy consumed Heat pump operating principle...
  • Page 12 2 Installation Regulation installation 2.2.3 Containment of refrigerant circuits and maintenance conditions It’s necessary to ensure correct containment In case of subsequent failure and expertise, the Unpacking and reservations 2.2.1 Receipt 2.2.2 Handling 2.2.4 Accessories provided Installation position Accessories provided with the outdoor unit Accessories provided with the hydraulic unit...

  • Page 13: Installation Of The Outdoor Unit

    Installation of the outdoor unit 2.4.1 Installation precautions The outdoor unit must only be installed outdoor 100 mm 100 mm 600 mm 250 mm 100 to 300 mm 300 mm For access 250 mm 300 mm 250 mm For access For access minimum 600 mm...
  • Page 14 H > 50 mm 2.4.2 Outdoor unit positioning In regions subject to frequent snow, (H) must be greater than the average snow layer Depending on the model 4 holes (Ø 10 mm) Depending on the model 4 holes 2.4.3 Condensate drain hose (Ø...
  • Page 15 Installing the hydraulic unit 2.5.2 Positioning the hydraulic unit 2.5.1 Installation precautions 350 mm mini 350 mm mini 538 mm mini 300 mm mini 300 mm 118 mm mini 1000 mm 188 mm 418 mm mini refrigerant connections. Mounting bracket...
  • Page 16 Refrigeration connections This appliance uses refrigerant R410A. 2.6.1 Rules and precautions Minimum necessary tools Manifold Provision on using tools that have been in 2.6.2 Refrigeration connections regard to the guarantee if the above instructions are not observed. only Flared connections is forbidden.
  • Page 17 2.6.3 Accessing the hydraulic module’s refrigerant connections Removing the casing 2.6.4 dimensions in mm ø Hose -0,4...
  • Page 18 HP model Outdoor unit connections Diameter Refrigeration Minimum length (L) connections Maximum length* (L) Maxi level difference (D) Male-female adapter (reduction) Hydraulic unit connections Hydraulic unit Outdoor unit mini mini...
  • Page 19 2.6.5 Shaping the refrigeration pipes 2.6.6 Designation Tightening torque 2.7, page 20 Take particular care positioning the tube opposite its connector so as not to risk damaging the threads. A carefully aligned connector can being required. The refrigeration circuit is very sensitive to dust and humidity: check that the area around the connection is clean and dry before removing the plugs protecting the refrigeration connectors.
  • Page 20 This operation is reserved for installers familiar Method 3 empty Manifold refrigerant other than a HFC. ANNEX 1 building the refrigerant connections. Jeu de manomètres Unfavorables conditions : Manifold Manifold (manifold) Basse Haute pression pression Vacuomètre Liaison... liquide Pompe à vide Azote Haute pression...
  • Page 21 First seal test Refrigeration connexion Plug (A) Schrader 3-way valve Manifold. Manifold Hex / Allen key of 4 mm Load orifice Azote Plug (B) Haute Service hose (blue) 10 bars max. pression fitted with valve push-button 30 mn mini Connexion of the hose on the "Gaz" valve Liaison...
  • Page 22 Hydraulic connecting 2.8.2 Rinsing out the installation 2.8.1 General 2.8.3 Filling and purging the installation Never use monoethylene glycol. page 29 In certain installations, the presence of different metals can cause corrosion problems; the formation of metal particles and sludge in the hydraulic circuit is then seen.
  • Page 23 Heating circulation pump speed settings 1 mbar = 10 mmCE = 100 Pa mbar Variable pressure ext. in radiators m /h ext. in 1 mbar = 10 mmCE = 100 Pa mbar ext. in Constant pressure m /h ext. in Cut off the electricity supply from the circulation pump for 30 seconds in order to release and authorise another start cycle.
  • Page 24 2.10 Electrical connections Flexible wires B 2.10.1 Characteristic of the electrical supply page 25 Connecting to regulation cards 2.10.2 General remarks on electrical connections Connecting to spring terminals Rigid wires Rigid wires A Flexible wires...
  • Page 25 2.10.3 2.10.4 Cable section and protection rating Heat pump (HP) Cable connection Model Maxi. power absorbed Curve D circuit breaker size (phase, neutral, earth) 16 A 20 A 25 A 32 A Heat pump (HP) Electrical back-ups Power supply to the electrical back-ups Cable connection Curve C circuit Model...
  • Page 26 Terminal block General electrical Interconnection supply between the external unit and the hydraulic module Remove the front panel Connections to outside unit’s terminal block (2 screws) Cover plate Insulation (seal) Cable clip Remove the front panel (2 screws) Power supply cable and connection cable Cover plate...
  • Page 27 2.10.6 Electrical connections on the hydraulic unit side hydraulic unit External faults the heat pump If the boiler connection option is used, the electric boost option must not be connected. Second heating circuit Access to hydraulic model electric box and description...
  • Page 28 Hydraulic unit Outdoor unit 1 2 3 230 V Connection to terminal block and power relays M B9 B2 M B1 3 2 1 Connections to the heat pump regulator (accessories and options)
  • Page 29 2.11 Outdoor sensor 2.13 Commissioning 2.12 Room thermostat and/or room control unit 2.12.1 Installing a room sensor Room thermostat T37 page 36 B2 M In the case of 2 heating circuits, Room thermostat T55 2.12.2 Installing a room control unit Room control unit T75...
  • Page 30 2.14 in zone 2, Then connect the other room thermostat and 2.15 In the case of 2 heating circuits: page 36 English 42* 44* 48* page 36 Line Function Setting range Setting Basic or display increment setting Room appliance 1 Heating circuit 1 Commonly...

  • Page 32: Regulation System

    3 Regulation system Auto Auto °C...
  • Page 33 Ref. Function Manual start button Auto page 56 Do not use during normal operation.
  • Page 34 Description of the display Temperature control 3.4.1 Set to Xxxxxxxxxxxxxxxxxxxxxxxxxxx Xxxxxxxxxxxxxxxxxxxxxxxxxxx Xxxxxxxxxxxxxxxxxxxxxxxxxxx User interface display Symbols INFO PROG temperature ambiante temperature ambiante temperature ambiante Closing the display...
  • Page 35 +4,5 -4,5 & & & & & & & & & Corrective actions in the case of discomfort...

  • Page 36: Parametering The Setting

    Parametering the setting 3.5.2 Setting parameters 3.5.1 General ESC. 01.01...31.12 3.5.3 Line Function Setting range Setting Basic or display increment setting Date and time 00:00... 23:59 01.01... 31.12 1900... 2099 01.01... 31.12 25.03 01.01... 31.12 25.10 User interface English Temporary...
  • Page 37 Line Function Setting range Setting Basic or display increment setting Heating time programme, circuit 1 Mon-Sun 6:00 22:00 --:-- --:-- --:-- --:-- Heating time programme, circuit 2 Mon-Sun 6:00 22:00 --:-- --:-- --:-- --:-- Mon-Sun 00:00 05:00 14:30 17:00 --:-- --:--...
  • Page 38 Line Function Setting range Setting Basic or display increment setting Time programme 5 / Cooling Mon-Sun 8:00 20:00 --:-- --:-- --:-- --:-- Holidays, heating circuit 1 Period 1 01.01... 31.12 01.01... 31.12 Frost protection Holidays, heating circuit 2 Period 1 01.01...
  • Page 39 Line Function Setting range Setting Basic or display increment setting 180 min 30 min 240 s Arrêt 0... 32 0... 32 Protection mode standards and instructions manufacturer performance of this function installation correctly This function can be stopped the adjustment on "Stop". Diagram of the concrete slab drying programmes...
  • Page 40 Line Function Setting range Setting Basic or display increment setting Cooling circuit 1 Time program 5 24 h 80 % 240 s Control 60 min Heating adjustment, Circuit 2 1010 1012 1014 1016 1020 1021 1030 1040...
  • Page 41 Line Function Setting range Setting Basic or display increment setting 1041 Important Note : 1050 50 % 1060 1060 1060 1090 180 min 1091 30 min 1100 1101 1130 1134 240 s 1150 Arrêt 1151 1156 0... 32 1157 0... 32 1200 Protection mode...
  • Page 42 Line Function Setting range Setting Basic or display increment setting 1610 1612 1620 Programme 24h / day Heating circuit time programme: Off-peak tariff* : 1640 1641 1642 Saturday 2056 240s 8 min 5 min 240 s 2916 2920 Released Released...
  • Page 43 Line Function Setting range Setting Basic or display increment setting 3692 Substitute 3700 3701 3705 20 min 3720 3723 30 min 5024 5030 90 min 5055 5057 Summer 5061 Release of 5093 5700 5710 5711 5715 5731 Diverting valve 2-stage complementary 6100 6120...
  • Page 44 Line Function Setting range Setting Basic or display increment setting 6220 0... 99 6420 1... 56 6421 LPB system 6600 Error 6711 Maintenance / special regime 7070 7071 0... 240 7073 0... 12 7141 7142 7150 Inputs / outputs test 7700...
  • Page 45 Line Function Setting range Setting Basic or display increment setting 7710 7712 7716 7719 7722 7723 7724 7725 Open 7911 7912 7913 7973 7974 7975 7976 7977 7996 Open State Generator diagnosis...
  • Page 46 Line Function Setting range Setting Basic or display increment setting 0... 65535 0... 65535 Diagnostics consumers...
  • Page 47 Line Function Setting range Setting Basic or display increment setting 0... 199999 0... 65535 9031 9032 9033 9034 9035 9050 9051 9052 9053 9054 9055 9071 9072 9073 9074 9075...

  • Page 48: Overall Hydraulic Layout

    4 Overall hydraulic layout...
  • Page 50 R (R) S (S) C (T) CN71 CN801 CN73 CN72 CN40 CN70 CN30 AOYA 18LALL Color Codes...
  • Page 51 CN90 CN64 CN42 CN40 CN200 CN400 1 2 3 4 1 2 3 4 5 1 2 3 4 5 6 7 8 9 1 2 3 4 5 1 2 3 4 5 6 7 8 9 1 2 3 4 CN62 CN65 1 2 3 4 5...
  • Page 52 R(R) S(S) C(T) AOYA 45 LBTL Color Codes...
  • Page 53 Noir Color Codes...
  • Page 54 Electrical wiring, Hydraulic module (Except installer's connections)

  • Page 56: Troubleshooting

    6 Troubleshooting Faults displayed on the hydraulic unit Hydraulic unit Heat pump operation Error number Error description Error location despite the error page 57. Hydraulic unit Diodes display Error contents LED 2 (green)
  • Page 57 Faults displayed on the outdoor unit Diode display Erroneous element Diode display Erroneous element Diode display Erroneous element...
  • Page 58 Information display Designation Line page 56...

  • Page 59: Maintenance Of The Installation

    7 Maintenance of the installation Checking the outdoor unit Hydraulic checks essential that you look for any leaks. Checking the refrigeration circuit Electrical checks 8 Maintenance Emptying the hydraulic unit Distribution valve 9 Instructions for the user...

  • Page 60: Quick-Start Procedure

    10 Quick-start procedure 10.1 Start-up check-list 10.1.1 Before starting-up Sight checks page 13 Hydraulic checks page 15 Refrigeration connections and checks page 16 page 20 Electrical checks page 24 page 27...
  • Page 61 10.1.2 Starting-up page 29 Outdoor unit checks Hydraulic unit checks Room control page 30...
  • Page 62 10.2 Settings sheet Setting Description Set to. Menus Setting Description Set to. Menus Boiler backup Preliminary settings language 3700 operator section 3705 swith-off delay hour / minutes time & date Miscellaneous day / month time & date 6420 year time & date 6100 5700 6120...
  • Page 63 10.3 Start-up data sheet Site Installer Outdoor unit Hydraulic unit Checks Operating voltage & current on outdoor unit Reading in HEATING operating mode Hydraulic system of hydraulic unit Options & accessories : Control settings...
  • Page 64 Date of installation : www.atlantic-comfort.com www.atlantic.fr Société Industrielle de Chauffage Contact of your heating technician or your after-sales service. SATC - BP 64 - 59660 MERVILLE - FRANCE...
