Configuration

Adjusting the Opto Sensor Sensitivity
(TallyPlus and ClockPlus)
The sensor trim control adjusts the threshold at which the opto sensor
(internal or external) causes the tally indication to change colour.
Turning the control clockwise lowers the threshold at which the unit
switches from green to red, effectively increasing the sensitivity of the
opto sensor.
If the tally status colour change is NOT required, the colour
can be set to a permanent green display by turning the
sensor trim control fully anti-clockwise.
18
Adjusting the Display Brightness (TallyPlus
and ClockPlus)
The brightness of the LED display digits can be adjusted with the BRI
switch. Two brightness levels are available.
Standard brightness
High brightness
