Troubleshooting - Autoscript TallyPlus User Manual

Fault
The accessory is not
Check that the DC power source is connected and secured.
powering up.
The tally indication Check that the appropriate tally connections for the installation have
(ClockPlus or been correctly made.
TallyPlus) is not
changing colour status.
Use the opto sensor trim control to adjust the switching threshold.
Check that the opto sensor is correctly positioned over the camera
tally light, and that the light is functioning.
Timecode is not being
displayed on the Check that the timecode source (LTC or VITC) has been connected
ClockPlus or has and is active.
become inaccurate.
Check

Troubleshooting

Comments
See the section Power Connections on
page 15.
See the section Directly Connecting the
Opto Sensor on page 13.
See the section Adjusting the Opto Sensor
Sensitivity (TallyPlus and ClockPlus) on
page 18.
See the section Mounting the Tally Opto
Sensor on page 8.
See the section Timecode Connections
(ClockPlus) on page 17.
23
