Technical Specification

Physical Data
TallyPlus
Width* 60 mm (2.4 in)
Height* 82 mm (3.2 in)
Depth* 31 mm (1.2 in)
Weight 0.15 kg (0.33 lb)
*Excluding controls/connectors.
Environmental Data (All Accessories)
Operating temperature range . . . . . . . .5°C to +40°C (41°F to +104°F)
Storage temperature range. . . . . . . . -20°C to +60°C (-4°F to +140°F)
Electrical Data
TallyPlus
Supply Voltage 12 VDC
Current (max) 0.22 A
Display Data (TallyPlus)
Format . . . . . . . . . . . . . . . . . . Seven segment LED display digit (0-9)
Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57.1 mm (2.25 in)
Display Data (ClockPlus)
Format . . . . . . . . Seven segment LED display digits (HH:MM:SS A/P)
Size (HH:MM:SS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 57.1 mm (2.25 in)
Size (A/P) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38.1 mm(1.5 in)
24
ClockPlus
383 mm (15.1 in)
88 mm (3.5 in)
34.5 mm (1.4 in)
0.8 kg (1.76 lb)
ClockPlus
12 VDC
1.6 A
Opto Sensor Data
Sensor . . . Light dependent resistor, 20k Ω at 10 Lux, 5K Ω at 100 lux
High illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . Red tally indication
Low illumination . . . . . . . . . . . . . . . . . . . . . . . . . Green tally indication
Connections Data
DC Power Socket (TallyPlus and ClockPlus)
Connector type: 2.1 mm DC socket.
TallyPlus Alternative DC Power Socket
Connector type: 3.5 mm mono jack socket.
Opto Sensor Socket
(TallyPlus and ClockPlus)
Connector type: 3.5 mm mono jack socket.
Pin Signal
Centre +12 VDC
Outer GROUND
Pin Signal
Centre +12 VDC
Outer GROUND
Pin Signal
Tip HOT
Sleeve GROUND
