3.
Fit the TallyPlus to the hood, aligning the fixing holes in the
brackets and securing with the two fixing screws provided.

Mounting the ClockPlus

WARNING! Before attempting to install or adjust
accessories, the tilt axis of the head support must be
securely locked horizontally (tilt axis).
The ClockPlus is mounted over the tally light on the front of the
prompter monitor.
1.
With the spacer plate in between, align the fixing thumbscrews on
the ClockPlus with the holes either side of the tally light on the
monitor. Ensure that the centre hole in the plate is correctly
aligned with the built-in opto sensor aperture.
Installation
11
