1-3. Parameter setting method

● When is selected in [1-2 Setting button operation], the input key of the setting value is shown as followings and the necessary data can be input.
● When the data out of the setting range is input, error message ("LIMIT ERROR") is shown on the input data display window with the error sound ("Beep").
▲ Input key for setting only the numbers
Input key for setting the pattern experiment name and DI ▶
error name Refer to [11. DI function and operation setting] in
[Operation manual] for DI error name input key.
▲ Input key for time signal setting ▲ Display when it is out of the setting range
Touch key lock release
● Input OFF (Lock release state) for key lock because the set value is not input when "Key lock" is "ON."
● Refer to [4. Operation motion setting] for details
6
