7-4. Time signal operation

● The time signal operation is classified into ON/OFF operation, time setting operation and the set time signal is used for setting the time signal No.
in segment setting in [7-1 Program pattern setting]
(1) Time signal ON/OFF operation
[Fig. 7-7] Time signal setting #1
1
2
The time signal is OFF during corresponding segment operation
①
when "0" is selected.
The change is impossible as it is only for reading.
●
3
The time signal is ON during corresponding segment operation
②
when "1" is selected.
The change is impossible as it is only for reading.
●
③
Moving the screen up/down by 6 time signal units.
3
