1-2. Setting button operation

Button type Button operation
The "Set value" is touched in stationary operation/still screen and it is used for setting the set value wanted by the user.
The "Pattern No." is touched in program still screen and it is used for setting the pattern number wanted by the user.
It is used for inputting the general numbers and name.
It is used for selection for one out of many types.
It is used for selection for one out of more than 2 parameter setting. (ON/OFF/Inactive state)
It is used for selection of Y/N for the corresponding parameter. (ON/OFF/Inactive state)
It is used for general screen conversion.
It is used for increasing or decreasing of the page within the same screen.
It is used for the page conversion by the decrease and increase in time axis on the same screen.
5
