Samwon Tech TEMI1000 Series Operation Manual page 20

(5) Stationary operation #3 operation screen
● The above screen is to display the measuring date, setting data of Temperature and Humidity. The direction of graph is horizontal.
● ( ) check box sets Y/N for data display.
● Possible to save recording values into the internal memory using this button
● The saved data into the internal memory are preserved when the electric power is "ON/OFF"
● Refer to [6-2 Present value (PV) graph view]
[Fig. 3-10] Stationary operation #3 operation screen
1
3 2
It displays the measuring data, setting data of currently operated
①
Temperature and Humidity.
It displays the capacity of internal memory.
②
About 90 days of saving is available when the sampling time is set in 1 second.
●
[Fig. 3-11] Stationary operation #3 operation screen (User Key)
It is a button to save the measuring data, setting data of currently
③
recorded Temperature and Humidity into the Internal memory.
18
