ICP DAS USA PEX-D56 Quick Start Manual

PEX-D56
56-channel DIO PCI Express board
Quick Start Guide
Product Website:
http://www.icpdas-usa.com/pex_d56.html
Introduction
The PEX-D56 cards are the new generation product that ICP DAS provides to meet
RoHS compliance requirement and is designed as completely compatible with the PIO-
D24/D56. Users can replace the PIO-D24/D56 by the PIO-D24U/D56U and PEX-
D24/D56 directly without software/driver modification.
The PEX-D56 supports PCI Express bus. The PEX-D56 consists of three 8-bit bi-
direction ports. The 8-bit ports are named as port A (PA), port B (PB) and port C (PC)
respectively. All ports are configured as inputs upon power-up or reset.
The PEX-D56 has a Card ID switch with which users can recognize the board by the ID
via software when using two or more PEX-D56 cards in one computer.
These cards support various OS versions, such as Linux, DOS, Windows 98/NT/2000
and 32/64-bit Windows 7/Vista/XP. DLL and Active X control together with various
language sample program based on Turbo C++, Borland c++, Microsoft C++, Visual
C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and
LabVIEW are provided in order to help users to quickly and easily develop their own
applications.
