Page 1 SmartAX MA5612 Multi-service Access Module V800R311C00 Maintenance Guide Issue Date 2012-07-25 HUAWEI TECHNOLOGIES CO., LTD.
Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
Page 3 Huawei alone is unable to collect or save the content of users' communications. It is suggested that you activate the interception-related functions based on the applicable laws and regulations in terms of purpose and scope of usage.
Page 4 SmartAX MA5612 Multi-service Access Module Maintenance Guide About This Document Symbol Description Provides additional information to emphasize or supplement important points of the main text. Command Conventions Convention Description Boldface The keywords of a command line are in boldface. Italic Command arguments are in italics.
Page 5 SmartAX MA5612 Multi-service Access Module Maintenance Guide About This Document The contents in 4 Troubleshooting Services Transmitted Through a GE Port Troubleshooting Services Transmitted Through a GPON Port are optimized. Issue 01 (2012-07-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Page 6: Table Of Contents
SmartAX MA5612 Multi-service Access Module Maintenance Guide Contents Contents About This Document........................ii 1 Overview............................1 1.1 Maintenance Purpose............................2 1.2 Maintenance Principle............................2 1.3 Maintenance Tools.............................4 2 Field Maintenance Guide......................6 2.1 Checking the Grounding of the Device......................7 2.2 Cleaning the Connector of the Optical Fiber......................8 2.3 Cleaning the Air Filter of the Cabinet......................10...
Page 7 SmartAX MA5612 Multi-service Access Module Maintenance Guide Contents 4.3.3 Busy Tone After Offhook........................84 4.3.4 Continuous Dial Tone During Dialing....................88 4.3.5 Called Party's Phone Does Not Ring.......................90 4.3.6 One-Way Audio or No Audio During Communication................93 4.3.7 Noise in Communication.........................95 4.3.8 Discontinuous Communication.......................99 4.3.9 Low Communication Voice........................100...
Page 8 SmartAX MA5612 Multi-service Access Module Maintenance Guide Contents 6.3 The Alarm Information Fails to Be Displayed on the NMS................231 6.4 Service Board Is in the Failed State........................232 6.5 A Service Board Fails to Register........................234 6.6 Repeated Board Reset.............................235 6.7 Unexpected Reset of the System........................237 7 Troubleshooting EMU Faults....................239...
Page 9 SmartAX MA5612 Multi-service Access Module Maintenance Guide Contents A.3.8 Label for Subscriber Cables........................308 A.3.9 Labels for DC Power Cables........................309 A.3.10 Labels for AC Power Cables......................310 A.4 Fault Tag................................311 Issue 01 (2012-07-25) Huawei Proprietary and Confidential viii Copyright © Huawei Technologies Co., Ltd.
Page 10: Overview
SmartAX MA5612 Multi-service Access Module Maintenance Guide 1 Overview Overview About This Chapter Describes the purpose of routine maintenance, basic maintenance principles, and required maintenance tools. 1.1 Maintenance Purpose This topic describes the maintenance purpose. 1.2 Maintenance Principle This topic describes the maintenance principle, including the following five parts: the...
Page 11: Maintenance Purpose
SmartAX MA5612 Multi-service Access Module Maintenance Guide 1 Overview 1.1 Maintenance Purpose This topic describes the maintenance purpose. The purpose of routine maintenance is to detect and rectify latent faults when the device is running and to collect data for analyzing and optimizing the network. This ensures that the system runs safely, stably, and reliably for a long time.
Page 12 Before replacing a part, estimate whether the risks can be controlled by technical protective measures without powering off the device. If yes, replace the part. If not, contact the local Huawei representative office for immediate technical support.
Page 13: Maintenance Tools
SmartAX MA5612 Multi-service Access Module Maintenance Guide 1 Overview When you open the cabinet door, prevent rain and snow from falling into the inner surface of the device (including the front panel of the service board), from falling into cables, or from falling into apertures.
Page 14 SmartAX MA5612 Multi-service Access Module Maintenance Guide 1 Overview Tool Description Appearance Adjustable Adjusts the optical optical attenuator power of optical signals by adjusting the optical attenuation. Flathead Fastens small screwdriver screws and bolts. The screwdriver has a flat head.
Page 15: Field Maintenance Guide
SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide Field Maintenance Guide About This Chapter This topic describes the tasks of maintaining the hardware of the MA5612, and the reference standard, operation guide, exception handling, and command reference of the tasks.
Page 16: Checking The Grounding Of The Device
SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide 2.1 Checking the Grounding of the Device To ensure that the device runs reliably and exclude the potential security risks, you need to check the grounding of the device periodically. To be specific, you need to check whether the ground cable is connected properly and whether the earth resistance meets the requirement.
Page 17: Cleaning The Connector Of The Optical Fiber
Bury the ground body or ground network deeper. l Use a larger ground body. l Decrease the resistivity of the earth. If the fault persists, contact Huawei technical support engineers. For details, see Contacting Huawei for Assistance. 2.2 Cleaning the Connector of the Optical Fiber This topic describes how to clean the connector of the optical fiber.
Page 18 SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide Cleaning tool box: used for placing the dust-free cotton and the dust-free cap. Place the dust-free cotton and the dust-free cap separately from other tools. Cleaning reagent (absolute ethyl alcohol) : used for cleaning the connector of the optical fiber.
Page 19: Cleaning The Air Filter Of The Cabinet
SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide If the optical transceiver can be removed and inserted, wear ESD gloves or an ESD wrist strap to remove it. Select dust-free cotton bars with different diameters according to the type of the optical port, dip one bar with the cleaning reagent, insert the bar into the inner of the optical port, and then clean it by rotating the bar 360 degrees along the inner wall of the optical port.
Page 20: Checking Batteries
SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide Do not exert extra force when removing the air filer. Otherwise, the air filter may be distorted. Do not install wet air filter into a cabinet. Otherwise, the cabinet will absorb drops during the air intake.
Page 21 SmartAX MA5612 Multi-service Access Module Maintenance Guide 2 Field Maintenance Guide – The joints between the batteries are firm and free of corrosion. – The spacing between the batteries is at least 10 mm. – The battery terminals are not bent or damaged. Damaged terminals cause high contact resistance or cracks in the battery shell.
Page 22: Checking The Surge Protector
10°C increase in temperature when the battery is operating outside the acceptable range. If the floating charge voltage is abnormal, replace the batteries. If the fault persists, contact Huawei technical support. For details on how to contact Huawei technical support, see 3.6 Contacting Huawei for Assistance.
Page 23 If the fault LED is red, the lightning proof function of the surge protector deteriorates or fails. In this case, replace the surge protector in time. If the surge protector is faulty, replace it. If the fault persists, contact Huawei technical support engineers. For details, see Contacting Huawei for Assistance.
Page 24: Engineers' Must-Read
3.6 Contacting Huawei for Assistance If the fault persists even after the troubleshooting measures described in this document have been taken, contact Huawei for assistance (Huawei engineers will provide guidance remotely or on site on troubleshooting). Issue 01 (2012-07-25) Huawei Proprietary and Confidential Copyright ©...
Page 25: Engineer Skill Requirements
Optical attenuator How to seek help in case of a fault, including but not limited to referring to the troubleshooting documents or contacting Huawei for assistance 3.2 Troubleshooting Precautions Before locating and troubleshooting faults, carefully read and strictly abide by the following precautions.
Page 26: Precautions For Replacing A Part
– Update the fault-related documents in time and place them in an easily accessible place (the latest documents can be obtained at http://support.huawei.com). 3.3 Precautions for Replacing a Part To ensure normal service running, read the following precautions carefully before replacing a part.
Page 27 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read Parts Impact on Services Optical transceiver Services carried on the optical port are interrupted. Cable Services carried on the cable are interrupted. Precautions for Replacing Boards Storage and transportation of boards When a board is outside the shelf (chassis), carry and place the board carefully.
Page 28 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read When inserting the board, make sure that you align the board with the board tracks and insert the board along the board tracks so that the board is in proper contact with the backplane.
Page 29 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read If an optical transceiver is difficult to remove, you can pull the handle bar of the optical transceiver and press the optical transceiver with your thumb on the side with the handle bar against the other side to remove the optical transceiver.
Page 30: Troubleshooting Procedure
SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read Parts Precautions Suggestions Optical l Select the optical fiber according to You can use a fiber extractor to remove fiber the type (single-mode or multi- an optical fiber. mode) of the optical transceiver,...
Page 31 Collecting and Recording the Fault Information A clear fault description can speed up fault locating no matter whether a fault is reported to a relevant department of carriers or to Huawei. Therefore, when a fault occurs, collect the fault information at the earliest time.
Page 32: Frequently Used Methods For Troubleshooting
SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read Locating and Rectifying the Fault According to the fault locating methods provided by the device, find out the root cause of the fault and take proper troubleshooting measures (for example, repairing the line, replacing the faulty parts, or modifying the configuration data).
Page 33 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read Configuration Data Analysis Incorrect re-configurations and expansion configurations, and outstanding problems of existing configurations are possible causes of a fault. Therefore, when locating and troubleshooting a fault, analyze the configuration data. Maintenance engineers need to master configuration methods and implementation principles of different services and functions to check the configuration data for different faults and to improve troubleshooting efficiency.
Page 34 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read To use the exclusive method, maintenance engineers must know stages where the fault may occur, and use applicable methods (such as loopback and configuration data analysis) to locate the fault. Therefore, maintenance engineers must be familiar with the following information:...
Page 35: Contacting Huawei For Assistance
Before contacting Huawei for technical support, fill in the form for reporting a fault shown in Table 3-3 and deliver this form to Huawei by fax or email. This can help us rectify the fault quickly for you. The more detailed and accurate the fault information you provide, the more helpful for subsequent fault locating.
Page 36 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read [YYYY-MM-DD XX (carrier name) in XX (region name)] XX (brief description of a fault) Fault symptom Including but not limited to: l Detailed fault symptom: Describe the fault symptom in detail.
Page 37 SmartAX MA5612 Multi-service Access Module Maintenance Guide 3 Engineers' Must-Read [YYYY-MM-DD XX (carrier name) in XX (region name)] XX (brief description of a fault) Operations that have already CAUTION When finding a fault (except an emergency that needs to be handled...
Page 38: Troubleshooting Services Transmitted Through A Ge Port
SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Troubleshooting Services Transmitted Through a GE Port About This Chapter This chapter describes how to troubleshoot common faults, such as Internet and Multicast service faults, when the MA5612 uses a GE port for upstream transmission.
Page 39: Troubleshooting Lan Internet Service
SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port 4.1 Troubleshooting LAN Internet Service This chapter describes how to troubleshoot local area network (LAN) Internet service faults on the MA5612. 4.1.1 Troubleshooting the Failure to Access the Internet This section describes how to troubleshoot failures associated with local area network (LAN) users accessing the Internet, for example, users fail to open Web pages.
Page 40 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Procedure Step 1 Check the user's PC. Check whether the user's PC can obtain the IP address. NOTE To view the IP address of the PC, do as follows: a.
Page 41: Troubleshooting The Failure To Obtain An Ip Address By Pppoe Dialup
If the user cannot access the Internet, go to Step Step 4 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 42 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Fault Location Location Analysis Possible Causes The configured service port data is The configured service port data, inconsistent with the data plan. such as the port ID, is incorrect.
Page 43 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Procedure Step 1 Perform a 8.9 PPPoE Dialup Emulation Test on the MA5612 for the affected user. If the result of the dialup emulation test is not "success," go to...
Page 44 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If the dialup is successful, go to Step l If the dialup fails, go to Step In ETH mode, run the display port state portid command to check whether the duplex mode, rate, network cable adaptation mode of the Ethernet port are consistent with those of the user terminal.
Page 45 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If the dialup fails, go to Step Step 5 Check the PITP configuration on the MA5612. Run the display pitp config command to check whether the current global PITP function is enabled.
Page 46 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 8 Check whether a user's MAC address has drifted on the MA5612. In global config mode, run the display location mac-addr command to check multiple times (more than three times is recommended) whether a MAC address drift occurred on the port that has learned the user's MAC address.
Page 47 If the dialup fails, go to Step Step 13 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 48: Troubleshooting The Failure To Obtain An Ip Address In Dhcp Mode
SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 14 End. ----End 4.1.3 Troubleshooting the Failure to Obtain an IP Address in DHCP Mode This section describes how to troubleshoot a failure to obtain an IP address in Dynamic Host Configuration Protocol (DHCP) mode.
Page 49 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Fault Location Location Analysis Possible Causes MA5612 The configured service port data is The configured service port data, inconsistent with the data plan. such as the uplink VLAN ID, is incorrect.
Page 50 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port NOTE If the test result is "send packet fail", "DHCP server not found", "DHCP server refuse request", or "get IP overtime", the upper-layer device of the MA5612 is faulty.
Page 51 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If they are inconsistent, modify the settings of the Ethernet port to ensure that the settings are consistent with those of the user terminal. Then, go to Step 3.8.
Page 52 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If a MAC address drift occurred on the port, go to Step 5.2. l If a MAC address drift did not occur on the port, go to...
Page 53: Troubleshooting Low Internet Access Rate
If the PC fails to obtain an IP address, go to Step Step 9 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 54 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Fault Location Location Analysis Possible Causes MA5612 The Internet access rate on a single l The rate restriction configuration port is low. for the user is incorrect.
Page 55 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port NOTE Query the statistics of the faulty port multiple times (recommended: 10 times) and then compare the statistics to check whether packet loss occurs on the subscriber line. The query interval is 20s.
Page 56: Troubleshooting Frequent Interruptions In Internet Service
If service is not normal, go to Step Step 9 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 57 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Fault Location Use the following guidelines to locate the fault. Fault Location Location Analysis Possible Causes User terminal The fault does not recur when the The user's PC is infected with user's PC is replaced.
Page 58 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If service is restored, the fault is on the user's PC. Check whether the NIC in the user's PC is faulty or whether the user's PC is infected with viruses. Then, go to...
Page 59: Troubleshooting The Multicast Service
If the service is not restored, go to Step Step 6 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 60 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port If the MA5612 receives the report packet, the multicast link is normal but the MA5612 fails to create a corresponding multicast entry. This is generally caused by incorrect multicast configurations on the MA5612.
Page 61 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Procedure Step 1 On the MA5612, run the display igmp user user-index command to query the multicast user status (State). l If State is block, the multicast user is blocked. In this case, run the undo igmp user block command to unblock the user.
Page 62 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Table 4-2 Incorrect multicast configurations of the MA5612 Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following...
Page 63 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 64 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 65 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause NOTE NOTE progra A multicast user can be bound to multiple To set permissions of the user for right profiles. If these right profiles are...
Page 66 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If the following symptoms occur, the Choose one of the following progra fault is because the program ordered is...
Page 67 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause belongs user belongs by running the display dynamically in the igmp program vlan command. MVLAN, and ensure that the IP address range includes the IP address of the ordered program.
Page 68: Blank Screen After Ordering A Program
If the user fails to go online, go to Step Step 8 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 69 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Fault Scope Possible Cause MA5612 On the MA5612, check whether the multicast user is online and then troubleshoot the fault according to the following symptoms:...
Page 70 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port On the MA5612, run the display multicast flow-statistic ip 224.1.1.1 vlan 3 command to query the traffic statistics of the ordered program on the upstream port (assume that the MVLAN ID is 3 and the IP address of the multicast program is 224.1.1.1).
Page 71 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Check the indicator status of the STB. If the indicator of the STB Ethernet port blinks quickly, the STB decoding may be incorrect. Reset the STB or use a functional STB.
Page 72 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Table 4-6 Troubleshooting method of incorrect multicast configurations on the MA5612 Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following...
Page 73 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following maximu occurs, the fault is because the available...
Page 74 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 75 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause NOTE NOTE progra A multicast user can be bound to multiple To set permissions of the user for right profiles. If these right profiles are...
Page 76 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If the following symptoms occur, the Choose one of the following progra fault is because the program ordered is...
Page 77 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause belongs user belongs by running the display be generated igmp program vlan command. dynamically in the MVLAN, and ensure...
Page 78 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following number occurs, the fault is because the number...
Page 79 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause The rate Run the display service-port Bind a traffic profile to multicast configu command to query the index of the Rx...
Page 80 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause There The prejoined static programs occupy Run the igmp program modify are too too many bandwidths. command to modify Prejoin to...
Page 81: Pixelation In A Multicast Program
Table 4-5. Step 5 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance). Step 6 End.
Page 82 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Location Method When pixelation occurs, Table 4-8 shows possible causes of the fault in different scopes. Table 4-8 Possible causes of the fault in different scopes...
Page 83 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Table 4-9 Troubleshooting method of faulty upper-layer network and devices Possibl Judgment Criterion Troubleshooting Method Cause Pixelation occurs when a user watches Replace the multicast source.
Page 84 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Table 4-10 Troubleshooting method of incorrect configurations of the MA5612 Possibl Judgment Criterion Troubleshooting Method Cause The rate Run the display service-port Bind a new traffic profile to...
Page 85 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause Run the display qos-info traffic-limit Run the traffic-limit command to port command to query the target rate change the target rate to an...
Page 86 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Run the igmp user modify user- maximu occurs, the fault is because the...
Page 87: Troubleshooting Voip Pstn Service
If the user cannot watch the program, go to Step Step 5 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 88 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Identify the fault scope The fault occurs on some The fault occurs on all The fault occurs on all ports ports ports on some boards...
Page 89 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port NOTE If the test result shown in Conclusion is AB all break off or no phone connected, the phone is faulty or the line between the phone and the MA5612 is not properly connected. In this case, replace the phone or check whether the line is connected properly.
Page 90: No Tone After Offhook
If the fault is not rectified, go to Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 91 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Identify the fault scope. The fault occurs on some The fault occurs on all The fault occurs on all ports ports. ports on some boards.
Page 92 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port If Conclusion is not Normal, rectify the fault based on the displayed test conclusion. Then, go to Step NOTE For example, if Conclusion is Phone not connected, the phone is faulty or the line between the phone and the device is not connected properly.
Page 93: Busy Tone After Offhook
If the fault persists, go to Step Step 15 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 94 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Confirm the voice protocol type H.248 protocol SIP protocol Check MG interface attributes Check SIP interface attribu Check the data of MGC subscribers Check the RTP format of the MG...
Page 95 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port l If such alarms or events are generated, clear these alarms or events to rectify the fault according to the relevant guide. Then, proceed to...
Page 96 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port If the test result (shown in Conclusion) is not Normal, rectify the fault based on the test result. Then, go to Step NOTE If the test result shown in Conclusion is Phone not connected, the phone is faulty or the line between the phone and the MA5612 is not properly connected.
Page 97: Continuous Dial Tone During Dialing
If no dial tone is heard, proceed to Step Step 15 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 98 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Procedure Step 1 Replace the phone and check whether the service is restored. If the service is restored, go to Step If the service is not restored, go to Step Step 2 Check whether the gain of the user port is set properly.
Page 99: Called Party's Phone Does Not Ring
If the service is not restored, go to Step Step 10 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 100 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Check whether the phone is working properly Check whether the subscriber line is normal Check whether the service boards are working properly Check whether the power board is...
Page 101 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 3 Check whether the service is restored. If the service is restored, go to Step If the service is not restored, go to Step Step 4 Replacing the service board and check whether the service is restored.
Page 102: One-Way Audio Or No Audio During Communication
Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 103 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port NOTE This fault is generally caused by an incorrect route configuration on the device or the bearer network. The signaling stream is deemed normal because the phone's abilities to dial and ring are normal. In this case, users connected to the same MA5612 can locate the cause by calling each other.
Page 104: Noise In Communication
If the fault persists, go to Step Step 10 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 105 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Confirm the fault scope. The fault occurs on The fault occurs on all subscribers of certain ports subscribers of the device. on the device.
Page 106 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Confirm the fault scope. If the fault occurs on all subscribers of the device, proceed to...
Page 107 If the fault persists, proceed to Step Step 12 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 108: Discontinuous Communication
SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 13 End. ----End 4.3.8 Discontinuous Communication This section describes how to troubleshoot the fault where the call is discontinuous. Fault Location Use the following guidelines to locate the fault:...
Page 109: Low Communication Voice
If the service is not restored, go to Step Step 6 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 110 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Start Check whether the phone is working properly Check whether the loop and circuit lines are normal Check whether the service board to which the affected user is connected...
Page 111 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 3 Check whether the fault is rectified. If the fault is rectified, go to Step If the fault persists, go to Step Step 4 Perform a 8.3 POTS Subscriber Circuit Line Test...
Page 112: Troubleshooting Fax And Modem Services
If the fault persists, go to Step Step 14 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 113 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Location Method Use the following guidelines to locate the fault: CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Confirm that the user followed the instructions given in the user manual of the fax machine when operating it and check whether the fax machine is faulty.
Page 114 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port NOTE Fax machines are relatively error-prone, especially multi-function fax machines. If any faults occur when using the fax services, use the following guidelines to identify the fault causes: l Check whether the fax machine is connected properly.
Page 115: Modem Service Failures
If the service is not restored, go to Step Step 13 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 116 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Location Method Use the following guidelines to locate the fault: CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Replace the modems of the calling and called party with phones, and check whether the two parties can communicate with each other normally.
Page 117 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port If the service is not restored, go to Step Step 4 Check whether the modem parameter configurations on the local MA5612 and peer MA5612 are consistent with the data plan.
Page 118: H.248-Based Isdn Pra Service Troubleshooting
If the service is not restored, go to Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 119: Sip-Based Isdn Pra Service Fault Troubleshooting
SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Step 3 Run the display iua-link state command to check the status of the IUA link. The IUA link can be used normally only when the IUA link is in active state.
Page 120 SmartAX MA5612 Multi-service Access Module Maintenance Guide 4 Troubleshooting Services Transmitted Through a GE Port Check whether the board connecting the PRA users is normal. Check whether the physical line is faulty. Procedure Step 1 Run the display if-sip all command to query the status of the SIP interface.
Page 121 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Troubleshooting Services Transmitted Through a GPON Port About This Chapter This chapter describes how to troubleshoot common faults, such as Internet and voice service faults, when the MA5612 uses a GPON port for upstream transmission.
Page 122: Troubleshooting Lan Internet Service
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port 5.1 Troubleshooting LAN Internet Service This chapter describes how to troubleshoot local area network (LAN) Internet service faults on the MA5612. Prerequisites The ONU and the OLT must communicate with each other normally. If a fault occurs in communication between the ONU and the OLT, all the services of the ONU are interrupted.
Page 123 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Location Location Analysis Possible Causes A Web site can be opened l The DNS is faulty and fails to resolve by entering its IP address.
Page 124: Troubleshooting The Failure To Obtain An Ip Address By Pppoe Dialup
Step Step 4 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 125 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Location Location Analysis Possible Causes If the fault does not recur when the The user's terminal is faulty. user's terminal is replaced, the fault is on the user's terminal.
Page 126 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Location Location Analysis Possible Causes A MAC address drift occurs. A user or BRAS MAC address may drift because of attacks or a loop on the network.
Page 127 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the dialup fails, go to Step Step 3 Check the interoperability between the user terminal and the MA5612. In ETH mode, run the display port state portid command on the MA5612 to check whether Active State of the Ethernet port is active.
Page 128 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the dialup fails, go to Step Replace the port and perform a dialup check. Then, check whether the dialup is successful. l If the dialup is successful, the original user port is faulty. Change the user's port and reconfigure the port data.
Page 129 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the dialup fails, go to Step Run the display pitp permit-forwarding service-port service-portid command to check whether the function that allows user-side PPPoE packets to carry vendor tags is enabled on the service port of the affected user.
Page 130 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Run the display location mac-addr command to check multiple times (more than three times is recommended) whether a MAC address drift occurred on the port that has learned the BRAS MAC address.
Page 131 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Change the ACL rule that restricts the transmission of PPPoE packets or delete the ACL configuration on the port. Then, perform another dialup check. l If the dialup is successful, go to...
Page 132: Troubleshooting The Failure To Obtain An Ip Address In Dhcp Mode
Step Step 14 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 133 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port If the test result is not "get IP successful", the link between the ONU and the upper-layer BRAS is unavailable. Use the following guidelines to locate the fault on the link.
Page 134 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Perform 8.11 DHCP Dialup Emulation Test for the affected user on the ONU.
Page 135 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If Link of the Ethernet port is online, go to Step 3.6. l If Link of the Ethernet port is not online, go to Step 3.7.
Page 136 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the uplink port was not added to the upstream VLAN, run the port vlan command to add the uplink port to the upstream VLAN, whose configuration must be the same as the configuration on the upper layer device.Then, go to...
Page 137 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Check whether the DHCP server is faulty and the IP address of the DHCP server is exhaust. Ensure the DHCP server work in the normal state. Check whether the PC can obtain an IP address.
Page 138: Troubleshooting Low Internet Access Rate
Step Step 10 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 139 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Location Location Analysis Possible Causes The Internet access rates on all The DBA bandwidth that the OLT ONU ports are low. allocates to the ONU is insufficient.
Page 140 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the Internet access is low, go to Step Step 4 Check whether unknown traffic is occupying the bandwidth on the ONU. Ensure that the user is not accessing the Internet. Run the display port statistics portid command to query the statistics of the Ethernet port multiple times (recommended: five times).
Page 141 Step Step 10 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 142: Troubleshooting Frequent Interruptions In Internet Service
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Step 11 End. ----End 5.1.5 Troubleshooting Frequent Interruptions in Internet Service This section describes how to troubleshoot frequent interruptions in Internet service when local area network (LAN) users on fiber to the building (FTTB) and fiber to the curb (FTTC) networks are accessing the Internet.
Page 143 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Procedure Step 1 Check the user terminal. Replace the user's PC and then check whether Internet service is restored. l If service is restored, the fault is on the user's PC. Check whether the NIC in the user's PC is faulty or whether the user's PC is infected with viruses.
Page 144: Troubleshooting Multicast Service
Step Step 6 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 145: Failure To Go Online Of A Multicast User
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port NOTE The following lists common faults in communication between the ONU and the OLT. 6.1 Abnormal ONU Status in GPON Upstream Transmission 6.1.1 GPON ONU Registration Failure 6.1.2 Failure to Auto Discover a GPON ONU...
Page 146 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Judgment Criterion Possible Cause Scope The ONU does not receive The IGMP function of the MVLAN on the ONU the report packet and all is disabled.
Page 147 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port huawei(config)#terminal monitor huawei(config)#terminal debugging huawei(config)#debugging igmp user Order the program again. Then, go to Step NOTE After the preceding steps are performed, run the following commands to disable the debugging function.
Page 148 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 149 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 150 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause NOTE NOTE progra A multicast user can be bound to multiple To set permissions of the user for right profiles. If these right profiles are...
Page 151 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If the following symptoms occur, the Choose one of the following progra fault is because the program ordered is...
Page 152 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause belongs user belongs by running the display dynamically in the igmp program vlan command. MVLAN, and ensure that the IP address range includes the IP address of the ordered program.
Page 153: Blank Screen After Ordering A Program
Step Step 8 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 154 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Scope Possible Cause On the ONU, check whether the multicast user is online and then troubleshoot the fault according to the following symptoms: l If the multicast user is offline or is blocked, troubleshoot the fault by referring to 5.2.1 Failure to Go Online of a Multicast...
Page 155 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Order a program again and perform the following steps to determine the location where program traffic interruption occurs.
Page 156 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Fault Scope Judgment Criterion Troubleshooting Method User terminal and Multicast streams reach the a. Check the user terminal upstream port of the ONU but do...
Page 157 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port NOTE After the preceding steps are performed, run the following commands to disable the debugging function. huawei(config)#undo debugging igmp huawei(config)#undo terminal debugging huawei(config)#undo terminal monitor...
Page 158 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following maximu occurs, the fault is because the available...
Page 159 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following multica occurs, the fault is because the multicast...
Page 160 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause NOTE NOTE progra A multicast user can be bound to multiple To set permissions of the user for right profiles. If these right profiles are...
Page 161 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If the following symptoms occur, the Choose one of the following progra fault is because the program ordered is...
Page 162 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause belongs igmp program vlan command on address range of the ONU. program groups that can be generated dynamically in the...
Page 163 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms Choose one of the following number occurs, the fault is because the number...
Page 164 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause The rate On the ONU, run the display service- Bind a traffic profile to multicast configu port command to query the index of the...
Page 165 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause There The prejoined static programs occupy On the ONU, run the igmp are too too many bandwidths, which is close to...
Page 166 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause NOTE bandwi – If Bandwidth management You can modify the attributes of all dths. switch is enable and Max multicast programs in any MVLAN.
Page 167 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Table 5-7 Troubleshooting method of incorrect multicast configurations of the OLT Possibl Judgment Criterion Troubleshooting Method Cause On the OLT, run the display igmp Choose one of the following...
Page 168 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause multicast user is included in the OLT to set the IP address OLT. MVLAN. range of program groups that can be generated...
Page 169 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If the following two queried results are Modify the ONU multicast mode different, the fault is because the ONU...
Page 170: Pixelation In A Multicast Program
5-5. Step 6 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 171 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Location Method When pixelation occurs in an FTTB or FTTC network, Table 5-9 shows possible causes of the fault in different scopes. Table 5-9 Possible causes of the fault in different scopes...
Page 172 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the queried result is far lower than the rate of the program traffic, the program traffic loses packets before reaching the ONU upstream port. It is assumed that the program traffic loses packets on the line between the OLT and the ONU.
Page 173 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If the user cannot watch the program, go to Step Step 4 Check the ONU. Find the possible cause according to judgment criteria described in...
Page 174 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause On the ONU, run the display qos-info On the ONU, run the traffic-limit traffic-limit port command to query command to change the target rate...
Page 175 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Possibl Judgment Criterion Troubleshooting Method Cause If one of the following symptoms On the ONU, run the igmp user maximu occurs, the fault is because the...
Page 176: Troubleshooting Voip Pstn Service
Step Step 6 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 177 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Identify the fault scope The fault occurs on some The fault occurs on all The fault occurs on all ports ports ports on some boards...
Page 178 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port NOTE If the test result shown in Conclusion is AB all break off or no phone connected, the phone is faulty or the line between the phone and the MA5612 is not properly connected. In this case, replace the phone or check whether the line is connected properly.
Page 179: No Tone After Offhook
If the fault is not rectified, go to Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 180 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Identify the fault scope. The fault occurs on some The fault occurs on all The fault occurs on all ports ports. ports on some boards.
Page 181 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port If Conclusion is not Normal, rectify the fault based on the displayed test conclusion. Then, go to Step NOTE For example, if Conclusion is Phone not connected, the phone is faulty or the line between the phone and the device is not connected properly.
Page 182: Busy Tone After Offhook
If the fault persists, go to Step Step 15 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 183 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Confirm the voice protocol type H.248 protocol SIP protocol Check MG interface attributes Check SIP interface attribu Check the data of MGC subscribers Check the RTP format of the MG...
Page 184 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port l If such alarms or events are generated, clear these alarms or events to rectify the fault according to the relevant guide. Then, proceed to...
Page 185 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port If the test result (shown in Conclusion) is not Normal, rectify the fault based on the test result. Then, go to Step NOTE If the test result shown in Conclusion is Phone not connected, the phone is faulty or the line between the phone and the MA5612 is not properly connected.
Page 186: Continuous Dial Tone During Dialing
If no dial tone is heard, proceed to Step Step 15 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 187 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Procedure Step 1 Replace the phone and check whether the service is restored. If the service is restored, go to Step If the service is not restored, go to Step Step 2 Check whether the gain of the user port is set properly.
Page 188: Called Party's Phone Does Not Ring
If the service is not restored, go to Step Step 10 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 189 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Check whether the phone is working properly Check whether the subscriber line is normal Check whether the service boards are working properly Check whether the power board is...
Page 190 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Step 3 Check whether the service is restored. If the service is restored, go to Step If the service is not restored, go to Step Step 4 Replacing the service board and check whether the service is restored.
Page 191: One-Way Audio Or No Audio During Communication
Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 192 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port NOTE This fault is generally caused by an incorrect route configuration on the device or the bearer network. The signaling stream is deemed normal because the phone's abilities to dial and ring are normal. In this case, users connected to the same MA5612 can locate the cause by calling each other.
Page 193: Noise In Communication
If the fault persists, go to Step Step 10 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 194 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Confirm the fault scope. The fault occurs on The fault occurs on all subscribers of certain ports subscribers of the device. on the device.
Page 195 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Confirm the fault scope. If the fault occurs on all subscribers of the device, proceed to...
Page 196 If the fault persists, proceed to Step Step 12 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 197: Discontinuous Communication
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Step 13 End. ----End 5.3.8 Discontinuous Communication This section describes how to troubleshoot the fault where the call is discontinuous. Fault Location Use the following guidelines to locate the fault:...
Page 198: Low Communication Voice
If the service is not restored, go to Step Step 6 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 199 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Start Check whether the phone is working properly Check whether the loop and circuit lines are normal Check whether the service board to which the affected user is connected...
Page 200 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port Step 3 Check whether the fault is rectified. If the fault is rectified, go to Step If the fault persists, go to Step Step 4 Perform a 8.3 POTS Subscriber Circuit Line Test...
Page 201: Troubleshooting Fax And Modem Services
If the fault persists, go to Step Step 14 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 202: Fax Service Failures
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port NOTE The following lists common faults in communication between the ONU and the OLT. 6.1.1 GPON ONU Registration Failure 6.1.2 Failure to Auto Discover a GPON ONU 6.1.3 GPON ONU Frequently Goes Online and Offline...
Page 203 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port If the user followed the instructions and the fax machine is normal, go to Step If the user did not follow the instructions or the fax machine is faulty, go to...
Page 204 If the service is not restored, go to Step Step 13 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 205: Modem Service Failures
SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port 5.4.2 Modem Service Failures This section describes how to troubleshoot common modem service failures, such as when dial- up Internet access fails or the modem goes offline repeatedly. Common modem services include the lottery service and point of sale (POS) service.
Page 206 SmartAX MA5612 Multi-service Access Module 5 Troubleshooting Services Transmitted Through a GPON Maintenance Guide Port If the modem tone cannot be heard, the called party modem cannot automatically start the modem service. Check the modem configurations to ensure that it can automatically start modem service.
Page 207 If the service is not restored, go to Step Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 208: System Fault Handling
SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling System Fault Handling About This Chapter This topic describes how to handle the following typical faults of the MA5612. 6.1 Abnormal ONU Status in GPON Upstream Transmission This section describes what to do if an optical network unit (ONU) is abnormal when the MA5612 uses a gigabit-capable passive optical network (GPON) port for upstream transmission.
Page 209: Abnormal Onu Status In Gpon Upstream Transmission
SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling 6.1 Abnormal ONU Status in GPON Upstream Transmission This section describes what to do if an optical network unit (ONU) is abnormal when the MA5612 uses a gigabit-capable passive optical network (GPON) port for upstream transmission.
Page 210 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Failure to Go Online of a GPON ONU An ONU connected to a GPON port of an OLT fails to go online normally, but the queried Run state of the ONU is displayed as offline by running the display ont info command on the OLT.
Page 211 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Fault Symptom Possible Cause Scope A single ONU or some l The branch fiber is bent excessively. ONUs connected to an NOTE l The branch fiber connector is not clean.
Page 212 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling CAUTION To facilitate fault report, save the results of the following steps. The parameters of the optical module in this topic comply with Class B+. Note that such parameters are slightly different from the parameters in Class C.
Page 213 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The actual distance Run the display port info Run the port range command between the ONU and command to query the to adjust the minimum logical...
Page 214 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The PON port is faulty. If either of the following two Replace the optical module of situations occurs, the PON pot the PON port or replace the is faulty.
Page 215 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The quality of optical 1. Test the backbone fiber and Splice the optical fiber again. fiber splicing is poor. For branch fiber by using the example, the splicing OTDR.
Page 216 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The optical attenuation If either of the following two Add an optical attenuator on the of the optical path is situations occurs, the optical optical path between the OLT excessively small.
Page 217 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The optical splitter is Measure the input and output Replace the faulty optical faulty or the connectors optical power of the optical splitter or clean the connectors...
Page 218 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method A rogue ONU (such as a If either of the following two Replace the rogue ONU with a continuous-mode ONU) situations occurs, a rogue ONU normal one.
Page 219 Step 5 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 220 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Fault Judgment Criterion Possible Cause Scope ONUs of the same type fail l The configurations issued by the OLT to recover their mismatch the actual ONU capabilities. configurations. A single ONU fails to The optical attenuation is over large or small and recover its configurations.
Page 221 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Procedure Step 1 When Config state of the ONU is displayed as failed, check whether the OLT generates the following alarm. If such an alarm is generated, clear it and check whether the fault is rectified.
Page 222 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The optical fiber is not 1. The return loss points of the l If the optical fiber is not firmly connected or backbone fiber and branch...
Page 223 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The ODN is not properly The ODN does not meet the Optimize the ODN to meet planned. requirements of the ODN link Huawei's ODN planning plan or GPON.
Page 224 Step 5 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 225: Failure To Auto Discover A Gpon Onu
Step Step 3 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 226 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Fault Symptom Possible Cause Scope A single ONU or some The actual distance between the ONU and OLT ONUs connected to an exceeds the ranging compensation distance OLT fail to be auto configured on the OLT.
Page 227 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Fault Symptom Possible Cause Scope A single ONU or some l The ONU is not powered on. ONUs connected to an l A rogue ONU (such as a continuous-mode...
Page 228 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The actual distance Run the display port info Run the port range command between the ONU and command to query the to adjust the minimum logical...
Page 229 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Step 2 Check for the possible causes on the ODN and troubleshoot the faults accordingly. If the ONU still fails to be auto discovered by the OLT after that, proceed to...
Page 230 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The multi-mode optical 1. Check the backbone fiber Replace the multi-mode optical fiber is used as the and branch fiber by using fiber with the single-mode backbone or branch the OTDR.
Page 231 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The ODN is not properly The ODN does not meet the Optimize the ODN to meet planned. requirements of the ODN link Huawei's ODN planning plan or GPON Class B+.
Page 232 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method A branch fiber break 1. Check the branch fiber by Reconnect the branch optical occurs. using the OTDR. It is found fiber. that a branch fiber break occurs.
Page 233: Gpon Onu Frequently Goes Online And Offline
Step 4 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 234 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Fault Symptom Possible Cause Scope All the ONUs connected to The PON port is faulty. a PON port on an OLT frequently go online and offline. All the ONUs connected to The board or the slot is faulty.
Page 235 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Procedure Step 1 When the "ONU frequently goes online and offline" alarm is generated, check whether the OLT generates the following alarms. If such alarms are generated, clear them and check whether the fault is rectified.
Page 236 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The optical fiber 1. Test the backbone fiber and Clean the optical fiber connector is not clean. branch fiber by using the connector. For details about OTDR.
Page 237 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Possible Cause Judgment Criterion Troubleshooting Method The optical splitter is Measure the input and output Replace the faulty optical faulty or the connectors optical power of the optical splitter or clean the connectors...
Page 238: Nms Fails To Manage A Device
Step 5 Record the results of the preceding steps in the form for reporting a fault (see Fault Report Form), fill out the entire form, and then submit the form to Huawei for technical support (see Contacting Huawei for Assistance).
Page 239 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling CAUTION To facilitate fault report, save the results of the following steps. Procedure Step 1 Check whether the same NMS fails to manage other devices, that is, whether the fault occurs in a large scale.
Page 240: The Alarm Information Fails To Be Displayed On The Nms
NMS. Step 11 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 241: Service Board Is In The Failed State
If the alarm information fails to be displayed on the NMS, go to Step Step 6 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 242 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Check whether the type of the inserted service board is the same as that configured in the system. Check whether the power supply for the service board is normal.
Page 243: A Service Board Fails To Register
If the fault persists, go to Step Step 9 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 244: Repeated Board Reset
If the new board is not working normally, go to Step Step 4 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 245 SmartAX MA5612 Multi-service Access Module Maintenance Guide 6 System Fault Handling Procedure Step 1 Run the display board frameid/slotid command to query the board information, and then check whether the configured board type is the same as the one in use.
Page 246: Unexpected Reset Of The System
If the new board does not work properly, go to Step Step 10 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 247 The working temperatures of the system range from -40°C to +65°C. Step 4 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 248: Troubleshooting Emu Faults
SmartAX MA5612 Multi-service Access Module Maintenance Guide 7 Troubleshooting EMU Faults Troubleshooting EMU Faults About This Chapter The EMU is used to monitor the running environment of devices. When the EMU is faulty, the fault is troubleshot immediately. This ensures that the devices and the services on the devices are normal because the running environment of the devices is monitored.
Page 249: Escm Being In Fault State
SmartAX MA5612 Multi-service Access Module Maintenance Guide 7 Troubleshooting EMU Faults 7.1 ESCM Being in Fault State The ESCM is an environment monitoring unit (EMU) that integrates the environment monitoring board, terminal blocks, and DIP switches. The ESCM monitors the environment parameters of the device.
Page 250: Eps30-4815Af Being In Fault State
If the ESCM is not in Normal state, go to Step Step 9 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 251 SmartAX MA5612 Multi-service Access Module Maintenance Guide 7 Troubleshooting EMU Faults Check whether the settings of the DIP switch on the EPS30-4815AF are the same as the settings of the secondary nodes of the EMU on the MA5612. CAUTION To facilitate fault report, save the results of the following steps.
Page 252 If the EPS30-4815AF is not in Normal state, go to Step Step 9 Record the results of the preceding steps in a fault report (see Fault Report Form), fill out the entire form, and then submit it to Huawei for technical support (see Contacting Huawei for Assistance).
Page 253: Common Operation
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Common Operation About This Chapter This topic describes the prerequisite, tools, impact on the system, and procedure of common operations of the device. 8.1 Performing a Loopback on an E1 Line The E1 line loopback is also called the 2M link physical loopback.
Page 254 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation helping them rectify hardware faults related to off-hook and playing of dial tone, busy tone, and ringback tones. 8.7 POTS Port Loop Test There are two kinds of loop tests: hardware tests and service tests. Loop tests used to test the hardware and data configuration associated with the plain old telephone service (POTS) service.
Page 255: Performing A Loopback On An E1 Line
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation 8.1 Performing a Loopback on an E1 Line The E1 line loopback is also called the 2M link physical loopback. When the services carried on an E1 port are abnormal, you can perform a loopback on the E1 line to check whether the E1 port is normal and whether the internal communication of the system is normal.
Page 256: Performing A Loopback On An E1 Port
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation References The E1 line loopback is also called the 2M link physical loopback. It is a type of hardware loopbacks, namely, the loopback on a manually created hardware loop. Figure 8-1 shows the E1 line loopback.
Page 257 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation After the port loopback is configured, the broadcast storm may occur if the E1 port is not isolated. Therefore, it is recommended that you run the undo loopback command to cancel the loopback in time after the loopback test is complete.
Page 258: Pots Subscriber Circuit Line Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Local loopback Remote loopback Local loopback on the E1 port Local loopback, also called inloop, is the loopback from the port processing module of the board to the backplane. In the local loopback, the signals that are transmitted from the backplane to the E1 port are directly sent back to the backplane to check whether the board that houses the E1 port can communicate with the backplane normally.
Page 259: Pots Subscriber Loop Line Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Context The user port to be tested must not be configured with any semi-permanent connection (SPC) service. The circuit line test (the test mode is mandatory test on busy) interrupts the services carried on the port to be tested.
Page 260: Pots Subscriber Search Tone Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Result The conclusions of the POTS subscriber loop line test are as follows: Normal: The subscriber loop line is normal. Touching the power line: The subscriber loop line touches the power line.
Page 261 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Procedure Step 1 Run the pots search-tone-test frameid/slotid/portid test-flag enable command in test mode to start the search tone test for a POTS user. Step 2 Use a phone receiver or other special instrument to check whether the tested line receives the signals.
Page 262: Pots Subscriber Signal Tone Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation 8.6 POTS Subscriber Signal Tone Test A signal tone test emulates a plain old telephone service (POTS) user's off-hook, triggering the system to send a test tone signal to a port on a voice service board. The port then sends the signal back to the system.
Page 263: Pots Port Loop Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Figure 8-5 Procedure for the signal tone test Loopback Plays signal tones CODEC SLIC Detects returned signal tones Voice service DSP chip board The test procedure is as follows: After an engineer starts the signal tone test, the DSP chipset sends a test tone signal to a port on the service board.
Page 264: Call Emulation Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation The test result is displayed after the test is complete. Perform a service test on a port. Run the pots path-test frameid/slotid port portid type business command in test mode to perform a service loop test on the port.
Page 265: Pppoe Dialup Emulation Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation l The procedure for performing a calling party emulation test is as follows: The user runs the pots emulational-caller caller-port command to start the calling party emulation test on the voice service port.
Page 266 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation NOTE The PPPoE dialup emulation is performed through the software, which occupies the CPU resources. Therefore, it is recommended that you perform the PPPoE dialup emulation when the system is not busy.
Page 267: Multicast Emulation Test
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation The PPPoE dialup emulation is performed by the MA5612 and the PPPoE dialup is started by a PC, modem, or home gateway. The MAC address of the PPPoE dialup emulation packet is the bridge MAC address of the MA5612.
Page 268: Dhcp Dialup Emulation Test
Run the display multicast flow-statistic command to query the real-time traffic of multicast programs. huawei(config-btv)#display multicast flow-statistic ip 224.1.1.1 vlan 4002 Command is being executed, please wait... Multicast flow statistic result: 296(kbps) After the query, it is found that the real-time traffic of multicast program whose IP address is 224.1.1.1 is 296 kbit/s, that is, the multicast source delivers the traffic.
Page 269 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation connectivity between the MA5612 and the DHCP server and verifies the DHCP configurations on a DHCP relay, DHCP proxy, and DHCP server. Context DHCP user configuration is correct. An MA5612 initiates DHCP dialup emulation. A PC, set top box (STB), or voice over IP (VoIP) terminal initiates common DHCP dialup.
Page 270: Capturing Voice Packets Remotely
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Route:1 Destination IP : 192.168.5.0/24 Next hop IP : 192.168.3.66 Next hop MAC Local interface : - Route:2 Destination IP : 192.168.4.0/24 Next hop IP : 192.168.3.88 Next hop MAC...
Page 271: Capturing Packets By Using Port Mirroring
SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Ensure that the source IP address can ping the IP address of the remote packet capture server. Run the remote-capture trace trace-value frame/slot/port frame/slot/port command to configure user information. Step 2 Start the remote packet capture software and wait until all required packets are captured.
Page 272 SmartAX MA5612 Multi-service Access Module Maintenance Guide 8 Common Operation Prerequisite The source port and destination port for mirroring must be Ethernet ports. The destination port cannot be an aggregated port. The destination port can be a METH port. The devices must be connected according to Figure 8-6.
Page 273 SmartAX MA5612 Multi-service Access Module Maintenance Guide 9 FAQ About This Chapter Analyze and answer the frequently asked questions of operating and maintaining the device. 9.1 How Is the Broadband Service Board Powered Off Automatically When the Battery Supplies Power...
Page 274: How Is The Broadband Service Board Powered Off Automatically When The Battery Supplies Power
SmartAX MA5612 Multi-service Access Module Maintenance Guide 9 FAQ 9.1 How Is the Broadband Service Board Powered Off Automatically When the Battery Supplies Power Question How is the broadband service board powered off automatically when the battery supplies power to the MA5612? Answer The MA5612 is configured with EPS30-4815AF.
Page 275: A Appendix
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Appendix This topic provides the reference information for maintaining the MA5612. A.1 Indicators The MA5612 provides a variety of indicators on its panel to help users learn about the running status of the device.
Page 276: A.1 Indicators
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix A.1 Indicators The MA5612 provides a variety of indicators on its panel to help users learn about the running status of the device. Figure A-1 Table A-1 list the LEDs on the panel of the MA5612.
Page 277: A.2 Making Cables And Connectors
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Description RUN/ALM: Running Red: on for 0.25s and off for The device is starting up. 0.25s repeatedly Green: on for 1s and off for 1s The device works in the normal repeatedly state.
Page 278: A.2.2 Making External Power Cables And Ground Cables With Cord End Terminals
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-2 Wire sequence of a console-Ethernet integrated cable A.2.2 Making External Power Cables and Ground Cables with Cord End Terminals This topic describes how to make external power cables and ground cables with cord end terminals.
Page 279 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-3 Peeling the insulation layer off the power cable Power cable Conductor CAUTION When peeling off the insulation layer of the power cable, ensure that the conductor of the power cable is not scratched.
Page 280: A.2.3 Making External Power Cables And Ground Cables With Ot Terminals
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-4 Inserting the conductor into the cord end terminal Power cable Cord end terminal CAUTION After the cord end terminal is inserted into the power cable, the conductor of the power cable outside the cord end terminal should not be longer than 1 mm.
Page 281 When peeling off the insulation layer of the power cable, ensure that the conductor of the power cable is not scratched. l If the bare crimping terminals are not provided by Huawei, you can adjust L1 according to the length of the crimping terminal. L1 = L + (1 or 2) mm.
Page 282 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Table A-3 Mapping between the cross-sectional area and the length of the insulation layer to be peeled off (L1) L1 (mm) Cross-Sectional Area (mm NOTE If you peel off the insulation layer off the power cable properly on site, you can compare the cable with the connector to be crimped.
Page 283 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix CAUTION After the OT terminal is installed, the length of the bare conductor outside the bare crimping terminal (L2) must not be more than 2 mm. If the length (L2) of the bare conductor outside the...
Page 284: A.2.4 Making Ordinary Network Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-9 Installing the heat shrink tubing ----End A.2.4 Making Ordinary Network Cables This topic describes how to make ordinary network cables. Components of an Ordinary Network Cable An ordinary network cable consists of two ordinary RJ45 connectors and one category-5 unshielded twisted pair (UTP-5) cable.
Page 285 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Ensure that the jacket is in proper condition. If the jacket is convex, plucked, or damaged, cut the improper part off the cable. Procedure Step 1 Use the diagonal pliers to cut the cable according to the required length.
Page 286 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-13 Assigning the wires to the network cable Wires arranged according to the order of network cables Table A-4 Wires assigned to the network cable Wire Wire Color Straight- Straight-...
Page 287: A.2.5 Making Shielded Network Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-14 Pushing the boot to cover the RJ45 connector ----End A.2.5 Making Shielded Network Cables This topic describes how to make shielded network cables. Components of a Shielded Network Cable A shielded network cable consists of two shielded RJ45 connectors and one super-UTP-5 cable.
Page 288 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-16 Components of a shielded RJ45 connector Metal cover on the RJ45 connector Wire fastening slot Shielded iron cover Boot Plastic cover of the RJ45 connector Procedure Step 1 Install the boot for the RJ45 connector.
Page 289 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-18 Installing the wires Step 3 Crimp the RJ45 connector. Insert the RJ45 connector into the metal cover. Use the diagonal pliers to crimp the metal part on the RJ45 connector. Ensure that the conductors inside the wires are properly connected to the metal part and the RJ45 connector is placed correctly.
Page 290: A.2.6 Making The E1 Cable
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix ----End A.2.6 Making the E1 Cable This topic describes how to make the E1 cable. Making the E1 Cable with the Straight SMB Female Connector This topic describes how to make the E1 cable with the straight SMB female connector.
Page 291 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Procedure Step 1 For the coaxial cable made of different materials, peel the coaxial cable to expose its outer conductor (D), insulation layer (E), and inner conductor (F) according to the lengths shown in Figure A-21.
Page 292 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Cable Type External Diameter L1 (mm) (mm) (mm) Remarks SFYV-75-2-2 4.4 mm 10-12 Dedicated to national backbone 155M-II Figure A-22 Lengths of connectors and the peeled part of cables Step 2 Put a coaxial cable into press-fitting sleeve A, as shown in Figure A-23.
Page 293 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Step 4 Insert the inner conductor and the insulation part of the coaxial cable into plug B of the connector. Wrap the outer conductor of the connector by using the outer conductor of the coaxial cable, as...
Page 294 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-27 Press-fitting the outer conductor ----End Follow-up Procedure After assembling the cable components, install the components on devices, as shown in Figure A-28. Figure A-28 Installing the components of a coaxial cable Making the E1 Cable with the Straight SMB Male Connector This topic describes how to make the E1 cable with the straight SMB male connector.
Page 295 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Tin wire Hot air gun Paper cutter marker Component Figure A-29 shows the components of the straight SMB male connector and the coaxial cable. Figure A-29 Components A: Press-fitting sleeve B: Plug of the connector...
Page 296 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-30 Structure of the coaxial cable Table A-6 Peeled lengths of commonly used coaxial cables External Cable Type Diameter (mm) L2 (mm) (mm) Remarks SYFVZ-75-1- 2.2 mm 10-12 1(A) SYV-75-2-2 3.9 mm...
Page 297 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-32 Putting a coaxial cable into a sleeve Step 3 Expand outer conductor D of the coaxial cable into a bell-mouthed shape as shown in Figure A-33. Figure A-33 Expanding the outer conductor of a coaxial cable Step 4 Insert the inner conductor and insulation part of the coaxial cable into plug B of the connector.
Page 298 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Step 5 Solder inner conductor F of the coaxial cable with the inner conductor of plug B, as shown in Figure A-35. Figure A-35 Soldering the inner conductor Welding NOTE After the welding, make sure that there is no metal wire (especially of the outer conductor) or redundant soldering tin between the inner conductor and the outer conductor.
Page 299 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-37 Installing the components of a coaxial cable Making the E1 Cable with the Bent SMB Female Connector This topic describes how to make the E1 cable with the bent SMB female connector.
Page 300 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-38 Components A: Press-fitting sleeve B: Screw of the connector C: Plug of connector D: Coaxial jacket E: Outer conductor of the F: Insulation layer of the G: Inner conductor of the...
Page 301 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix CAUTION l When peeling the coaxial cable, do not damage the outer conductor or the shielded layer of the coaxial cable. l You can determine the length of the part to be peeled according to the length of the connector,...
Page 302 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-41 Putting a coaxial cable into a sleeve Step 3 Insert the inner conductor and the insulation part of the coaxial cable into plug C of the connector. Wrap outer conductor E of the connector by using the outer conductor of the coaxial cable, as...
Page 303 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix NOTE After the welding, make sure that there is no metal wire (especially of the outer conductor) or redundant soldering tin between the inner conductor and the outer conductor. Use the multimeter to test the insulation state between the inner conductor and the outer conductor.
Page 304: A.3 Cable Labels
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-46 Installing the components of a coaxial cable A.3 Cable Labels This topic describes how to make, fill in, and attach the cable label. Labels are attached to the cables to identify the physical positions of the cables on different devices.
Page 305 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Label for the Signal Cable The label for the signal cable is L-shaped and of a fixed size. Figure A-47 shows the label for the signal cable. Figure A-47 Label for the signal cable 84.0...
Page 306: A.3.2 Filling Labels
Template for the Printing You can obtain the template through the following two ways: Download the template from the technical support website "support.huawei.com". The path is as follows: Related Links > Engineering Service > Engineering Quality > Quality Standard and Template.
Page 307 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Setting the Printer To print the labels, use a laser printer. The type of the laser printer is not limited. Before printing a label, set up the page and print on an ordinary paper as follows: Place the ordinary printed paper on the label paper.
Page 308: A.3.3 Usage Of Labels
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix To maintain the labels legible and neat, use the black oil marker (excluding the ball pen) delivered with the products to write on the labels. In special cases, you can use a black ballpoint pen, although it is not recommended to use a ballpoint pen.
Page 309 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix For the Signal Cable The two sides of the label attached to the signal cable indicate the location of the ports connected to both ends of the cable, as shown in Figure A-51.
Page 310: A.3.4 Attaching Labels
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix A.3.4 Attaching Labels After printing or writing the label on the base page, remove the label from the base page, and then attach the label to the cable or the identification plate of the cable tie. The following describes how to attach the label for the signal cable and the power cable.
Page 311 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-53 Attaching the label to the signal cable Affixing side 2-3 mm A01 2 Attaching the Label to the Power Cable Remove the label from the bottom of the label page, and then attach it to the concave part on one side of the identification plate.
Page 312: A.3.5 Label For External Alarm Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-54 Appearance of the label attached to the power cable Cable -48V2 Cable 1-The identification plate is on top 2-The identification plate is at the right of the cable in horizontal cabling side of the cable in vertical cabling A.3.5 Label for External Alarm Cables...
Page 313: A.3.6 Label For Network Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-55 Example of the label on the alarm cable A.3.6 Label for Network Cables This topic describes the application scope, content, and meaning of the label for the network cable, and provides the example of filling in the label.
Page 314: A.3.7 Labels For Optical Fibers
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix For the network cables that connect to the hubs, servers, or agents of the VAS devices, the information on the labels is provided according to the actual conditions. For the cable from the hub to the server, specify the cabinet number and subrack number where the hub is located, and specify the serial number on the hub.
Page 315 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Content Meaning Example B: Subrack number The subracks are numbered from bottom to top. 01 indicates the lowest subrack. C: Slot number The slots are numbered from left to right and from top to bottom. 01 indicates slot 5 of the subrack.
Page 316 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Meaning of the Label for Optical Fiber Connecting the Cabinet to the ODF Table A-12 describes the information on the label for the optical fiber connecting the cabinet to the ODF.
Page 317: A.3.8 Label For Subscriber Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix "ODF-G01-01-01-R" indicates that one end of the optical fiber is connected to the optical receiving terminal in row 01, column 01 of the ODF in row G, column 01. "A01-01-05-05-T" indicates that the other end of the optical fiber is connected to optical receiving interface 05 in slot 05, subrack 01 in the cabinet in row A, column 01.
Page 318: A.3.9 Labels For Dc Power Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix "A01-03-01-01" indicates that the local end of the subscriber cable is connected to terminal 01 in slot 01, subrack 03 of the cabinet in row A, column 01. "MDF-G01-01-01" indicates that the peer end of the subscriber cable is connected to the terminal in row 01, column 01 of the MDF in row G, column 01.
Page 319: A.3.10 Labels For Ac Power Cables
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Figure A-60 Example of the labels on the DC power cable A01 -48V2 Label on the loaded cabinet side (position of the cable on the power distribution cabinet side) -48V2 Label on the power distribution frame side (position of the cable on the loaded cabinet side) On the loaded cabinet side, the label marked as "A01/B08- -48 V2"...
Page 320: A.4 Fault Tag
SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix BGND, and PGND cables have the insulation sheath. Hence, you only need to write "AC" and the cabinet number on each label. The labels for AC power cables are attached to one side of the identification plate on the cable tie.
Page 321 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Tel.: Fax: Category*: Return Analysis Goods Fault Description Category Software Code Description Code* occurring of the Fault No.* Version* Date* Phenomena* Reasons for Repairing (Category No.): Category No. includes the following 8 types: l F001–wear out damaged (In warranty Period, Out of Warranty Period)
Page 322 SmartAX MA5612 Multi-service Access Module Maintenance Guide A Appendix Notes: l For optical boards that are returned, the optical interface should be covered with a safety cap. l As usual, the analysis board will not be returned to you , if you have any special requirements, please contact the technical support.
