5.1. iMag/ iMag Pro(II) Unencrypted Data Output Format

<Start Sentinel 1><T
Track 1:
<Start Sentinel 2><T
Track 2:
<Start Sentinel 3><T
Track 3:
Where:
Start Sentinel 1 = % Start
Sentinel 2=;
Start Sentinel 3 =; for ISO, % for AAMVA End Sentinel all tracks
= ?
Start or End Characters in the encoding format come before the first data character (start) and after the last
data character (end), indicating the beginning and end of data.
Sentinel:
Track Separator: A designated character that separates data tracks. The default character is NULL.
Terminator: A designated character that comes at the end of the last track of data, to separate card reads. The
default character is CR (Carriage Return).
Example:
%B4352378366824999^TFSTEST
/THIRTYONE^05102011000088200882000000?;4352378366824999=05102011000088
2?
iMag/ iMag Pro uses ID TECH's enhanced data encryption format where all data tracks are encrypted.
Output Format:
<STX><LenL><LenH><Card Data><CheckLRC><CheckSum><ETX>
0 STX
Data Length low byte
1
Data Length high byte
2
3 Card Encode Type
4 Track 1-3 Status
5 Track 1 data length
6 Track 2 data length
7 Track 3 data length
8 Clear/mask data sent status
Encrypted/Hash data sent
9
status
4
10 T1 clear/mask data
T2 clear/mask data
T3 clear/mask data
T1 encrypted data
T2 encrypted data
T3 encrypted data
Session ID (8 bytes) (Security
Data><End Sentinel><Track Separator>
1
Data><End Sentinel><Track Separator>
2
Data><End Sentinel><Terminator>
3
1
2
3
