Configuration

Menu Display and Operation

The setup menu is navigated and configured using the menu buttons,
with the following display interface:
Current selected item
Other items
Adjustable range
Item description

Main Menu Items

All the available main menu items are shown in the following tables,
with any values that can be changed by the user, together with the
video input(s) applicable. Where there is a variable parameter the
maximum and minimum limits or options are shown.
Item Adjustable range
Brightness 0 - 64
Contrast 0 - 64
Color 0 - 64
Tint 0 - 32
18
Current item value
Video Input
AV / VGA
AV / VGA
AV
*The menu item Dimmer does not function. To adjust the backlight see
the section Backlight Control Buttons on page 17.
AV
Item Adjustable range
Sharpness 0 - 16
Dimmer* See note
Color Tone Normal / Warm / Cool
Mirror OFF/ON
Flip OFF/ON
H Position -25 - +25
V Position -10 - +10
Auto
Scan Over Scan / Under Scan
Information
Setup See the section Setup
Menu Items on page 19
Factory Set
Exit
Video Input
AV
See note
AV / VGA
AV / VGA
AV / VGA
AV / VGA
AV / VGA
VGA
AV
AV / VGA
AV / VGA
AV / VGA
AV / VGA
