Servo Checking and Required Mode Modification

Check the stick function of remote controller. (The follow example is demonstrated as transmitter Mode2
which means left hand is throttle.)
Please take off all propellers before the following calibrations in case any danger occurs.
Under Manual Mode:
1. Make sure the aircraft is in centre position.
2. Push the throttle-stick the motor speed will increase,and pull back the throttle-stick, the motor speed will
decrease.
3. Push the pitch-stick the two V-type tail will go down.
4. Pull back the pitch-stick the two V-type tail will go up.
5. Turn the aileron-stick to the left, the left aileron will go up, and the right one will go down.
6. Turn the aileron-stick to the right, the right aileron will go up, and the left one will go down.
