  • Page 1 BABY SHARK 260 VTOL User Manual 2019.05 V2.0...
  • Page 2: Table Of Contents

    FOXTECH BABY SHARK 260 VTOL User Manual Contents Specifications Basic Theory Setup and Calibration Assembly Check Radio Control Download Mission Planner Connect Baby Shark to Computer Connect the Datalink and Check Flight Controller Checklist before Every Flight Test Flight Autopilot Applications Appendix ESC Calibration Servo Checking and Required Mode Modification...
  • Page 3: Specifications

    Flight Controller DA16S+ Radio Controller x1 Controller Optional -SEEKER-20 20X Optical Zoom Camera with 3-Axis Gimbal -SEEKER-30 Max 30X Optical Zoom Camera with 3-Axis Gimbal -FOXTECH 3DM V2 Oblique Camera for Mapping and Survey 2019 FOXTECH All Rights Reserved ©...
  • Page 4: Basic Theory

    User Manual Basic Theory BABY SHARK 260 VTOL features a highly advanced aerodynamic design. It is made of high density composite material, which features high strength and very light weight. BABY SHARK VTOL adopts quick- detach design which makes the plane easy to set up and transport. The fuselage also has big inner space to hold flight controller, batteries or other equipments.
  • Page 5: Setup And Calibration

    FOXTECH BABY SHARK 260 VTOL User Manual Setup and Calibration Assembly 1.Connect the two motor cables 2.Fix the arm on the aileron with 3.Insert the two carbon fiber tubes and the signal cable. the two screws. in the body. 4.Install the wings.
  • Page 6: Check Radio Control

    FOXTECH BABY SHARK 260 VTOL User Manual Check Radio Control 1.Check transmitter mode(left hand throttle or right hand throttle). 2.Check channels on the transmitter. Download Mission Planner Download the latest Mission planner online or copy it from the SD card.
  • Page 7 FOXTECH BABY SHARK 260 VTOL User Manual 2019 FOXTECH All Rights Reserved ©...
  • Page 8 FOXTECH BABY SHARK 260 VTOL User Manual 3. Enter the "Device Manager" interface and find its COM. 4. Select correct Com port, and click CONNECT. 2019 FOXTECH All Rights Reserved ©...
  • Page 9: Connect The Datalink And Check Flight Controller

    FOXTECH BABY SHARK 260 VTOL User Manual 5. Connection completed. Connect the Datalink and Check Flight Controller 1.Calibrate the Accelerometer Although the accelerometer was calibrated already for the PNP version before shipping, please calibrate it again since it might be affected in the transportation.
  • Page 10 FOXTECH BABY SHARK 260 VTOL User Manual 2. Compass Calibration Baby Shark VTOL uses high sensitivity compass and it has to be re-calibrated when fly in a new place. Enter the compass setting page and click”start” , hold the plane and rotate it in order to hit all directions on a sphere to calibrate the compass, when it’s done, a new offset would be given to the flight controller, and a...
  • Page 11 FOXTECH BABY SHARK 260 VTOL User Manual 2019 FOXTECH All Rights Reserved ©...
  • Page 12 FOXTECH BABY SHARK 260 VTOL User Manual 4. Check Flight Modes. (Cruise, QHover, QLoiter, Loiter, Auto, RTL) 2019 FOXTECH All Rights Reserved ©...
  • Page 13 FOXTECH BABY SHARK 260 VTOL User Manual 5. Calibrate the Airspeed Sensor It is critical that you calibrate airspeed meter to ensure that it is working correctly, and ensure that it is correctly zeroed. After you start up APM on your aircraft you should wait at least 1 minute for your electronics to warm up, preferably longer, and then do a pre-flight calibration of your airspeed sensor.
  • Page 14: Checklist Before Every Flight

    FOXTECH BABY SHARK 260 VTOL User Manual Checklist before Every Flight Make sure all items are checked before every flight. 1. The aircraft connection is stable and normal. 2. All screws and nuts are not loose. 3. The propeller is in the normal direction and is fastened.
  • Page 15: Test Flight

    FOXTECH BABY SHARK 260 VTOL User Manual Test Flight Before the first flight, it’s suggest to check if every component is well connected, Servos working properly, motors spinning to the correct direction and all control surfaces are moving to the desired directions.
  • Page 16 FOXTECH BABY SHARK 260 VTOL User Manual If everything goes well, you can try to land. First, reduce the altitude by pushing forward the elevator and when the altitude is around 50m above the ground, switch to Qhover(or Qloiter) Mode. Then become a multicopter again, then you can land it just as a normal multicopter.
  • Page 17: Autopilot

    FOXTECH BABY SHARK 260 VTOL User Manual Autopilot After the first flight, you can try to do autopilot. You can choose to take off and land either by manual control or automatically. To use automatic taking off and landing, you can change the first waypoint to VTOL_TAKE OFF, and set an...
  • Page 18: Applications

    FOXTECH BABY SHARK 260 VTOL User Manual Applications - Survey - 3D Survey - Patrol - FPV - Air pollution detection More autopilot mode can be found in Mission planner manual, like circle survey, Grid, drop an object with hook at desired waypoint.
  • Page 19: Appendix

    FOXTECH BABY SHARK 260 VTOL User Manual Appendix The following calibrations are for Customers who bought Baby Shark VTOL Kit. For the customers who bought Baby Shark PNP combo, the following calibrations are done before shipping. Please donot change any settings. If the settings are changed by accident, please recover from the param. document in the SD card.
  • Page 20 FOXTECH BABY SHARK 260 VTOL User Manual 4. In the following demonstration, Take Left hand throttle as an example. Push throttle to Max.(Pic 4-1), connect Baby Shark with power, when there is “di di ~ di” sound quickly push throttle to Min.(Pic 4-2) When there is “di di di di ~di”...
  • Page 21: Servo Checking And Required Mode Modification

    FOXTECH BABY SHARK 260 VTOL User Manual Servo Checking and Required Mode Modification Check the stick function of remote controller. (The follow example is demonstrated as transmitter Mode2 which means left hand is throttle.) Please take off all propellers before the following calibrations in case any danger occurs.
  • Page 22 FOXTECH BABY SHARK 260 VTOL User Manual 7. Turn the direction-stick to the left,the left V-type tail will go up, and the right tail will go down. 8. Turn the direction-stick to the right,the right V-type tail will go up, and the left tail will go down.
  • Page 23 FOXTECH BABY SHARK 260 VTOL User Manual 4. Pull the pitch-stick, the speed of the front motor will increase and the back motor will decrease, the two V-type tail will go up. 5. Turn the aileron-stick to the left, the left motor speed will decrease, and the right motor speed will increase left aileron goes up, and the right aileron goes down at the same time.
  • Page 24: Angle Deviation Compensation Checking

    FOXTECH BABY SHARK 260 VTOL User Manual Angle Deviation Compensation Checking Unlock the plane under the Q_STABLIZE mode: 1. Plane leans forward, the speed of the front motors will increase, the back motor-decrease,the two V-type tails go up. 2. Plane leans back, the speed of front motors will decrease, the back motor-increase, the two V-type tails go down.
  • Page 25: Default Setttings

    FOXTECH BABY SHARK 260 VTOL User Manual Default Setttings Some default setttings in Pixhawk for Baby Shark. 1. Baby Shark Pixhawk Basic Settings for Reference. 2. Suggested ”Q_VFWD” is: 0.05 , this setting will increase anti-wind performance in QLOITER mode and Vtol-take off and landing.
  • Page 26 FOXTECH BABY SHARK 260 VTOL User Manual 7. Suggested “Q_WP_SPEED_DN” is: 250 Suggested “Q_WP_SPEED_UP” is: 200 8. Suggested “Q_LAND_FINAL_ALT” is: 10 Suggested “Q_LAND_SPEED” is: 50 9. Suggested “Q_TRAN_PIT_MAX” value is: 7 10. Suggested “WP_RADIUS” value is: 30 11. Suggested “BATT2_AMP_OFFSET” value is: 0.027 Suggested “BATT2_AMP_PERVLT”...
  • Page 27: Pixhawk Connections

    FOXTECH BABY SHARK 260 VTOL User Manual Pixhawk Connections This content is subject to change. Download the latest version from https://www.foxtechfpv.com/foxtech-baby-shark-vtol.html For everyday updates, please follow Foxtech Facebook page: https://www.facebook.com/foxtechhobby YouTube Channel: https://www.youtube.com/user/foxtechonline/featured?view_as=subscriber 2019 FOXTECH All Rights Reserved ©...
