Foxtech Nimbus VTOL V2 User Manual page 16

FOXTECH Nimbus VTOL V2(DA16S Combo) User Manual
You can fly a while and see if the plane could go straight, if you find the plane is tilting left for example, don't
try to trim the aileron with your radio, the trim to aileron(SERVO1) must be done in parameter setting. (If
the elevator trim is necessary, please trim the SERVO2 and SERVO4 at the same time with the same trim
amount.)
If everything goes well, you can try to land. First, reduce the altitude by pushing forward the elevator and
when the altitude is around 30m above the ground, switch to Qhover(or Qloiter) Mode, two front motors
will tilt upwards to 60degrees, the plane will glide a while until the speed is lower than 12m/s, then the front
motors will tilt straight up and the plane is then become a multicopter again, then you can land it just as a
normal multicopter.
