SETTING UP YOUR
FIOS HOmE WI-FI ExTENDER
2.0/ SETTING UP YOUR FIOS HOME WI-FI EXTENDER
Note: Using a wired backhaul, the Fios Home Wi-Fi Extender
can be placed at a location distant from the Fios Home Router,
and positioned for optimum coverage. Using Wi-Fi backhaul,
performance can be slower and the distance from the router will be
determined by the reach of Wi-Fi from the Fios Home Router, the
materials in the home, and neighboring Wi-Fi traffic. Wi-Fi backhaul
is an effective and convientient in home Wi-Fi configuration, but
based on Wi-Fi interference charastics, does not perform as well
as a wired connection.
2.0a/ WIRED INSTALLATION
1. Connect the Fios Home Router to a coax outlet. (If the coax
outlet is already in use, use the coax splitter included in the
box.)
2. Connect the Fios Home Wi-Fi Extender to a coax outlet -
ideally in an area with spotty Wi-Fi coverage.
3. Connect the power cord from the router and extender to an
electrical outlet.
