Graco SmartWare 262370 Instructions - Parts Manual

Shot dispense kit, accurate metered dispensing kit for one component materials. kits are compatible with check-mate pumps and dura-flo pumps; both alone and as part of a supply system, for professional use only
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions - Parts
SmartWare
Dispense Kit
Accurate metered dispensing kit for one component materials. Kits are compatible with
®
Check-Mate
pumps and Dura-Flo
professional use only.
Not approved for use in European explosive atmosphere locations.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Kit 262370 for D200 and D60
For D200 3 inch dual post ram with NXT
For D60 3 inch dual post ram with NXT2200 and larger air motors
Kit 262371 for D200
For D200 3 inch dual post ram with NXT1800 and smaller air motors
Kit 262372 for D200S
For D200S 6 inch dual post ram with NXT2200 and larger air motors
Kit 262373 for S20
For S20 3 inch single post ram NXT2200 and larger air motors
Kit 262374 for S20
For S20 3 inch single post ram with NXT1800 and smaller air motors
Kit 262375 for pumps
For wall mount or floor stand pump with NXT2200 and larger air
motors
™
Shot
™
pumps; both alone and as part of a supply system. For
®
2200 and larger air motors
Kit 262370 Shown
3A0294J
EN
