Appliance dimensions - AGA DC3
DESN 516358 B
Fig. 1.1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
mm 987 951 913 680 1388 760 1145 698 116
10
559 813
30
634 422 849
Cooker Dimensions
When surveying for a cooker installation the actual clearance required for the 'body' of the appliance
should be increased by 10mm beyond the figures quoted above. This allows safe margin to take into
account the natural dimensional variations found in major castings. In particular the width across the
appliance recess could be critical.
APPLIANCE WEIGHT (Excludes Packaging)
Model: AGA Dual Control (DC3) - 444kg
