Electrified Exit Device Installation Example; Recommended Power Supplies - Command access MLP-UL-M KIT Insert Instructions

Electrified Exit Device
Installation Example
Ceiling Tile
Module
Retr of it 2-pi n Co nne ctor
The new 2-pin connector is used when retrofitting a older Command or
Von Duprin installation so you can plug in to the exisiting connector.
New
PU SH N' GO Connect or
STRIPE WIRE 1/8"-3/16" 7 INSERT INTO WIRE ACCESS HOLES OF CONNECTOR.
WIRE ACCESS
WIRE RELEASE
R ecommend ed Po w er Su ppli e s:
All Command Access exit devices & field installable kits have been thoroughly
cycle tested with Command Access power supplies at our factory.
For more information
U S C U S T O M E R S U P P O R T 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | W W W . C O M M A N D A C C E S S . C O M | C A C U S T O M E R S U P P O R T 1 - 8 5 5 - 8 2 3 - 3 0 0 2
CAT
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
Legend
Standard Placement
Optional Placement
E x i s it n g
click here or go to our website
GREEN
CHANNEL 1
LED
+
-
