Installation instructions
Compact speed monitor M18
UK
DC design, IO-Link, with connector
DI5029
DI5030

Advertisement

Table of Contents
loading

Summary of Contents for IFM DI5029

  • Page 1 Installation instructions Compact speed monitor M18 DC design, IO-Link, with connector DI5029 DI5030...
  • Page 2: Table Of Contents

    Contents 1 Preliminary note ���������������������������������������������������������������������������������������������������3 1�1 Symbols and warnings used �������������������������������������������������������������������������3 2 Safety instructions �����������������������������������������������������������������������������������������������4 3 Functions and features ����������������������������������������������������������������������������������������4 4 Function diagrams �����������������������������������������������������������������������������������������������4 4�1 Single point mode �����������������������������������������������������������������������������������������4 4�2 Window mode �����������������������������������������������������������������������������������������������5 5 SIO mode�������������������������������������������������������������������������������������������������������������7 5�1 Switching function normally open �����������������������������������������������������������������7 5�2 Switching function normally closed ���������������������������������������������������������������7 6 IO-Link mode �������������������������������������������������������������������������������������������������������7 6�1 LED display ��������������������������������������������������������������������������������������������������8...
  • Page 3: Preliminary Note

    1 Preliminary note This document applies to devices of the type "compact speed monitor" (art� no�: DI5029 and DI5030)� This document is intended for specialists� These specialists are people who are qualified by their training and their experience to see risks and to avoid possible hazards that may be caused during operation, installation or maintenance of the device�...
  • Page 4: Safety Instructions

    2 Safety instructions A qualified electrician must connect the unit� Observe the national and international regulations for the installation of electrical equipment� 3 Functions and features The inductive compact speed monitor with IO-Link determines the frequency [pulses/min] with which the sensor is damped without contact� The device compares the measured value with the switching thresholds and switches the outputs according to the configuration�...
  • Page 5: 4�2 Window Mode

    1: Power-on delay time 2: Start-up delay 3: Normally open 4: Normally closed 4.2 Window mode Normally open (switch point logic = 1) SP1: switch-on point window SP1+hyst: switch-off point SP2: switch-on point window SP2 hyst: switch-off point Normally closed (switch point logic = 0) SP1: switch-off point window SP1+hyst: switch-on point...
  • Page 6 1: Power-on delay time 2: Start-up delay 3: NO 4: NC...
  • Page 7: Sio Mode

    You will find the IODDs necessary for the configuration of an IO-Link device and detailed information about parameter setting tools and process data structure, diagnostic information and parameter addresses at www�ifm�com/gb/io-link�...
  • Page 8: 6�1 Led Display

    6.1 LED display Status LED status In the measuring range yellow (permanently on) Outside the measuring range (UL) yellow (flashing) 2 Hz mark-to-space ratio 1:1 Outside the measuring range (OL) yellow (flashing) 2 Hz mark-to-space ratio 1:1 After power-on in the IO-Link mode => "NO yellow (flashing) 2 Hz mark-to-space DATA“...
  • Page 9 SSC2 Param SP1 Setpoint 1 5���24000 pulses/min default = 5 pulses/min SSC2 Param SP2 Setpoint 2 3���21600 pulses/min default = 3 pulses/min SSC2 Config Logic Setpoint logic / State for NO / NC target detected default = NO SSC2 Config Mode Setpoint mode single point / window / two-point mode...
  • Page 10: 6�2�1 Setting Range And Conditions For Parameter Setting

    6.2.1 Setting range and conditions for parameter setting To properly set the device parameters the value line below has to be observed� It gives important information about the setting range and the resulting conditions� Conditions: 5 ≤ SP1 ≤ 24000 3 ≤...
  • Page 11: 6�2�2 Start-Up Delay

    6.2.2 Start-up delay The start-up delay suppresses an error signal as long as the machine is in the process of starting and has not yet reached its minimum speed� After application of the operating voltage the start-up delay is active only once� If the plant is started and stopped frequently, linking the drive and speed monitor power supplies ensures that the start-up delay is effective each time the machine is switched on (→...
  • Page 12: 6�3 Diagnostics And Events

    6.3 Diagnostics and events Code Name Type Description 20480 d / 50 00 h Device hardware Error Device Exchange fault 35856 d / 8C 10 h Process variable Warning Process data uncertain� range over-run Note: This event will not be transmitted via IO-Link Event mechanism�...
  • Page 13: Installation

    7 Installation Mounting principle Mounting specifications ► Fix the device using a bracket and secure it by means of the nuts provided so that it cannot work loose� ► Adhere to the above mounting specifications to ensure a correct function� 7.1 Tips on flush and non-flush mounting in metal Installation instructions cylindrical design flush...
  • Page 14: Electrical Connection

    Side-by-side installation only possible with different oscillator frequencies� 8 Electrical connection ► Disconnect power� ► Connect the device according to the wiring diagram� 8.1 Wiring DI5029, DI5030 SIO: 4 Switching output PNP/NPN programmable via IO-Link IO-Link: 4 IO-Link communication Factory setting...
  • Page 15: Operation

    LED 4 x 90° LED 4 x 90° DI5029 DI5030 Dimensions [mm] Data sheets and EC declarations of conformity can be found at: www�ifm�com EPS Source EPS Source Product Scale Drawing Product Scale Drawin Frame Size: 80 mm x 22,5 mm Frame Size: 80 mm x LED 4 x 90°...
