View these instructions online at www.lbwhite.com

Kit Contents:

DESCRIPTION
Instructions, installation
Remote fuel hook-up
Bracket, mounting
Screws, 5/16 in. hex head
Cap, pipe, 3/8" NPT
Hose, 3/8" x 15"
Nipple, 3/8" x 1-1/2", black
Elbow, 3/8" NPT, female, Galv.
Blue Cap
Pipe Compound
Hose Adapter
Reducing Bushing, 3/8" MNPT x 1/4" FNPT

Qualifications for installation of the kit:

• You must be able to read and understand these instructions.
• You must be properly trained and have sufficient experience in servicing oil heaters and capable of testing the
heater for proper operation.

General information:

The following instructions provide information on converting a two-pipe system to a one pipe system with the use of the
remote fuel hook-up.

Safety instructions:

• To prevent leaks, always apply approved PTFE tape or piping compound to all connections.
• Tighten all connections securely.
WORLD PROVIDER - INNOVATIVE HEATING SOLUTIONS
411 Mason Street, Onalaska, WI 54650 • 800-345-7200 • 608-783-5691 • 608-783-6115 (fax) • www.lbwhite.com
INSTALLATION INSTRUCTIONS
Remote Fuel Hook-up
Foreman 230/500 Oil

Tools required:

- Adjustable wrench
QTY.
- 9/16 in. wrench
1
- 3/4 in. wrench
- Pipe wrench
1
- Portable drill with 5/16 in. socket or 5/16 in. nut driver
1
Materials required:
4
• Rags or towels
1
• Appropriate PTFE thread sealant tape for use with fuel oil.
2
• Appropriate pipe fittings for connection to 3/8 in. inlet of fuel
1
filter (used for drawing fuel from external fuel tank).
1
1
1
3
1
500-131261

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Foreman 230 Oil and is the answer not in the manual?

Questions and answers

Summary of Contents for L.B. White Foreman 230 Oil

  • Page 1: Kit Contents

    INSTALLATION INSTRUCTIONS Remote Fuel Hook-up Foreman 230/500 Oil 500-131261 View these instructions online at www.lbwhite.com Kit Contents: Tools required: - Adjustable wrench DESCRIPTION QTY. - 9/16 in. wrench Instructions, installation - 3/4 in. wrench - Pipe wrench Remote fuel hook-up - Portable drill with 5/16 in.
  • Page 2 Remote Fuel Hook-up Foreman 230/500 Oil If you are attaching an external fuel tank to A. Initial Preparation: the heater, continue to C3. Otherwise, skip 1. Have a sufficiently large enough fuel resistant to section C8. container ready to catch any fuel expelled from the pump during removal of the hoses.
  • Page 3 Remote Fuel Hook-up Foreman 230/500 Oil 2. Attach the remote hook-up bracket to the fuel filter 7. Wrap the cord of the blue cap around the elbow bracket, as shown, using the mounting screws and press fit the cap onto the threads of the bush- provided with kit.
  • Page 4 Contact your local L.B. White dealer for replacement such as Western Global ® parts and service. You may also call the L.B. White Co., LLC. at 1-800-345-7200, for assistance, or email When using an external fuel tank, the burner will us at customerservice@lbwhite.com.
