4 DIGIDRIVERIP - DIGISTRIPIP50 - DIGISTRIPIP100

1.2 DIGISTRIPIP100

DIGISTRIPIP100 is a linear LED video fixture for the rental market wih 10 mm pixel pitch and an extensive
range of optical accessories for a wide variety of looks (black and white milk included, transparent on de-
mand). Each strip features 100 LED RGB/FC LEDs with individual pixel control, 1 meter long, 120° viewing
angle. The mechanics of DIGISTRIPIP100 have been studied to grant a great mounting flexibility through a
sliding hardwares on the back for truss application and on the side for multiple vertical linking. The exter-
nal control unit DIGIDRIVERIP is compatible with Art-Net and Kling-Net protocol, and runs both signal and
power over a 4 poles cable that provides greater stability and connection in daisy chain (10 DIGISTRIP for
each port up to 20 DIGISTRIPIP100 totaly).
LIGHT SOURCE
• Source:100 x 0,25 W RGB LEDs
• Lux:1174 lux with clear cover lux
• Source Life Expectancy: >50.000 h
OPTICS
• Pixel pitch:10 mm
• Additional Optics:black cover, milky dome cover and flat white milky cover
COLOR SYSTEM
• Color Mixing: RGB/FC
BODY
• Body: Sturdy aluminum profile
• Body Color:White optic and body Black
CONTROL
• Control units:DIGIDRIVERIP
• Art-Net Channels:300 ch
• Protocols: Art-Net, Kling-Net
• Pixel Control: Pixel2Pixel control
ELECTRICAL
• Power Supply: DC 48 V
PHYSICAL
• Signal Connection: 4p in/out
• Power Connection: 4p in/out
• IP:65
• Suspension And Fixing: Bracket for truss rigging and hardware for connection of more units
• Dimensions (WxHxD):1000x34x100 mm
• Weight:2,7 kg
34
1000
Disegno tecnico Fig.2
