Villager
V 46 T / VR 46 T (GB)
FŰNYÍRÓ
Villager V 46 T / Villager VR 46 T
Eredeti használati útmutató
VIGYÁZAT:
Olvassa el és tartsa be az összes biztonsági előírást és utasítást a gép üzemeltetése előtt.
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V 46 T and is the answer not in the manual?

Questions and answers

Summary of Contents for Villager V 46 T

  • Page 1 Villager V 46 T / VR 46 T (GB) FŰNYÍRÓ Villager V 46 T / Villager VR 46 T Eredeti használati útmutató VIGYÁZAT: Olvassa el és tartsa be az összes biztonsági előírást és utasítást a gép üzemeltetése előtt.
  • Page 2 Villager V 46 T / VR 46 T (GB) Köszönjük, hogy a benzines fűnyírót választotta Annak érdekében, hogy a benzinüzemű fűnyíróval legjobb eredményt érje el, figyelmesen olvassa el ezeket a biztonsági és üzemeltetési utasításokat mielőtt használná ezt a terméket. Models Villager V 46 T - Toló...
  • Page 3 LÁSD V46E Dokumentum 2-16. oldal!! Villager V 46 T / VR 46 T (GB) Drive lever ( only for VR 46 T ) Brake lever Knob Water nozzle Grass catcher Fuel cap Starter handle Prime button Air filter Height adjust handle...
  • Page 4 Villager V 46 T / VR 46 T (GB) - refuel outdoors only and do not smoke while refueling; - add fuel before starting the engine. Never remove the cap of the fuel tank or add petrel while the engine is running or when the engine is hot;...
  • Page 5 Villager V 46 T / VR 46 T (GB) -before refueling; u) reduce the throttle setting during engine shut down and, if the engine is provided with a shutoff valve,turn the fuel off at the conclusion of mowing; Maintenance and storage a) Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition;...
  • Page 6 Villager V 46 T / VR 46 T (GB) CAUTION! Sharp cutting tool! Keep hands and feet away from the cutter bar! Caution! Hot surfaces! Risk of burns! Risk of bruises and injuries from sharp edges; Never touch the dangerous places, when the blade is in motion.
  • Page 7 Villager V 46 T / VR 46 T (GB)  Stop the engine and disconnect the spark plug. before clearing blockages or unclogging chute. before checking, cleaning or working on the lawnmower. after striking a foreign object. Inspect the lawnmower for damage and make repairs before restarting and operating the lawnmower.
  • Page 8: Assembly / Pre-Operation

    Villager V 46 T / VR 46 T (GB) servicing them.  Do not change the engine governor setting or over speed the engine.  Use extreme caution when reversing or pulling the lawnmower towards you.  Stop the blade(s) if the lawnmower has to be tilted for transportation when crossing surfaces other than grass, and when transporting the lawnmower to and from the area to be mowed.
  • Page 9: Drive Control

    Villager V 46 T / VR 46 T (GB) Operation Drive lever (only for VR 46 T ) Push handle Brake lever Brake lever-must be held down to the handle to start the engine. Release to stop the engine. Starter handle - used for starting engine.
  • Page 10: Adjust Cutting Height

    Villager V 46 T / VR 46 T (GB) ADJUST CUTTING HEIGHT Raise wheels for low cut and lower wheels for deep cut, adjust cutting height to suit your requirements. Medium position is best for most lawns. BEFORE STARTING ENGINE ADD OIL Before each subsequent use the oil level must be check and if necessary topped up with 500ml SAE30 engine oil.
  • Page 11: Start Engine

    Villager V 46 T / VR 46 T (GB) CAUTION: Alcohol blended fuels, called gasohol or using ethanol or methane can attract moisture which leads to separation and formation of acids during storage. Acidic gas can damage the fuel system of an engine while in storage.
  • Page 12: Maintenance

    Villager V 46 T / VR 46 T (GB)  Keep top of engine around starter clear and clean of grass clippings and chaff. This will help engine air flow and extend engine life. MAINTENANCE IMPORTANT-Regular, careful maintenance is essential for keeping the safety level and original performance of the machine unchanged in time.
  • Page 13: Changing Blades

    Villager V 46 T / VR 46 T (GB) CHANGING BLADES To replace the blade, undo the screw. Empty the oil tank before removing the blade Reinstall as illustrated. Tighten the screw properly. Tightening torque 45 Nm. When replacing the blade, the blade screw should also be replaced.
  • Page 14: Paper Element

    Villager V 46 T / VR 46 T (GB) Air Filter Unclip the air filter cover and remove the sponge filter element. To avoid objects falling into the air intake, replace the air filter cover. FOAM ELEMENT PAPER ELEMENT AIR CLEANER COVER DRAINING THE FUEL TANK AND CARBURETOR 1.
  • Page 15: Maintenance Schedule

    Villager V 46 T / VR 46 T (GB) MAINTENANCE SCHEDULE REGULAR SERVICE PERIOD Before First Every 3 Every 6 Every Every Each Month Months Months Year Years ITEM 5 Hrs 25 Hrs 50 Hrs 100 Hrs or 250 Hrs...
  • Page 16: Troubleshooting

    Villager V 46 T / VR 46 T (GB) TROUBLE SHOOTING ENGINE WILL NOT START Possible Cause Correction 1.Check fuel. Out of fuel. Refuel Bad fuel;engine stored without Drain the fuel tank and carburetor treating or draining gasoline, of (p.5). Refuel with fresh gasoline.
  • Page 17 Villager V 46 T / VR 46 T (GB) STORAGE The same petrol must not remain in the tank for more than one month. Thoroughly clean the mower and store it indoors in a dry place. THE ENVIRONMENT In order to protect the environment, we recommend that the following points should be given special consideration: ...
  • Page 18 According to the Machinery Directive 2006/42/EC of 17 May 2006, Annex II A A Gép leírása: Benzines fűnyró Villager V 46 T / VR 46 T Teljes körű felelősségvállalással kijelentjük, hogy az alábbi terméket az alábbiak szerint tervezték és gyártották: ...

This manual is also suitable for:

Vr 46 t
