internal Ethernet ports on the library control blade (LCB) to the Ethernet
port marked "LOWER" located on the bottom right of the expansion
module in which the Ethernet Expansion blade is installed. There are
two ports, marked "UPPER" and "LOWER." Since the Ethernet Expansion
blade must be installed in the lower bay of the expansion module, you
must use the port marked "LOWER." The "LOWER" port is on the right.
See Figure 1 on page 2. You must do this BEFORE placing the Ethernet
Expansion blade into the library.
• Tape drives connected to an Ethernet Expansion blade must not be
connected to an FC I/O blade. Instead, connect them to a host or switch.
