G O B O R E P L A C E M E N T
7. REPLACING A ROTATING GOBO - Locate the specific Rotating GOBO to replace. Carefully gripping the GOBO
using your index finger, gently lift it slightly, and then with a pair of needle-nose pliers, pull on the tab to pull it out
and away until it fully clears the GOBO Wheel.
8. Locate the tab of the spring, and with a precision pick (or similar tool), carefully press the retaining spring inward
to relieve the tension. Remove the retaining spring and carefully separate the GOBO from the GOBO Holder. Install
the replacement Rotating GOBO following the steps above in reverse order
CAUTION: TAKE CARE NOT TO SCRATCH GOBO OR GOBO HOLDER
