DCA-8000
4.3 An extension cord should not be used unless absolutely necessary. Use of an improper exten-
sion cord could result in a risk of fire and electric shock. If an extension cord must be used,
make sure:
a. that the pins on plugs of the extension cord are the same number, size, and shape as
those of the plug on the charger;
b. that the extension cord is properly wired and in good electrical condition;
c. that the wire size is large enough for the AC ampere rating of charger as specified in the
following table.
AC input rating Amps
Equal or greater
than:
8
10
12
14
16
*American Wire Gauge
5

Charger Location

Not for permanent installation: Modifying this charger for permanent installation in a vehicle or
installing this charger in a vehicle for permanent use is not recommended.
This charger is NOT designed outside use or for wet location mounting. The charger must always
be protected from direct contact with water.
5.1 The charger must be located in an area with sufficient air space to allow unrestricted airflow in and
around the charger.
5.2 Locate the charger as far away from the battery as the charger cables permit.
5.3 Never place the charger directly above the battery being charged; gases from the battery will
corrode and damage the charger.
5.4 Never allow battery acid to drip on the charger when taking gravity readings or filling a flood-
ed cell battery.
5.5 Operate the charger only in a well-ventilated area that is free of dangerous vapors.
5.6 Store the charger in safe, dry location and maintain it in perfect condition.
5.7 Do not set the battery on top of the charger or where its acid might drip onto the charger.
www.midtronics.com
Recommended minimum AWG* size
for extension cords for battery chargers
But less
than:
25 (7.6)
10 18
12 16
14 16
16 16
18 14
In the event of fail device may generate
and emit sparks.
Only charge rechargeable flooded maintenance-
free, low-maintenance or deep-cycle batteries.
General Safety Precautions
AWG* size of cord
Length of cord, feet (m)
50 (15.2) 100 (30.5) 150 (45.6)
14 12
14 10
12 10
12 10
12 8
10
8
8
8
8
9
