1 Overview

1.1 General

Like the anchor SIMATIC RTLS4330A, the gateway SIMATIC RTLS4330G represents a
reference point for localization in the SIMATIC Locating Manager. The RTLS4330G gateway
can be connected to the local IT infrastructure via Ethernet. The localization data collected by
the nodes (anchors and gateways) and optionally customer-specific data is exchanged between
the wireless localization network and the localization server via this connection. For larger
localization networks, the use of multiple gateways is recommended to increase the number of
localizable transponders and the availability of position information.

1.2 Scope of delivery and accessories

1 SIMATIC RTLS4330A (article number 6GT2701-5EA03)
or
1 SIMATIC RTLS4330G (article number 6GT2701-5EB03)
Accessories (not included in scope of delivery)
1 power cable (Bulgin 400 Series Buccaneer® PX0410/03S)
•
3-pin, 5 m (article number 6GT2791-2AH50)
Bayonet connector (Amphenol RCP-00BMMS-TLM7001) made of plastic for RJ45 connector for
•
cable mounting (IP65) at gateway (article number 6GT2790-0CB00)
Holder for ceiling suspension of anchor/gateway (article number 6GT2790-0BE20)
•
Holder for corner/mast mounting of anchor/gateway (article number 6GT2790-0BE30)
•

1.3 Supply voltage

The device can be operated with a DC voltage of 8 to 30 volts.
The supply voltage of the device must not exceed the following values:
U < 30 V; I < 3.3 A; P < 100 W
The RTLS4330G gateway can be powered via a power plug or Ethernet (PoE), not both at the
same time. The device is a class 0 device according to PoE.
SIMATIC RTLS4330A / SIMATIC RTLS4330G
Manual, 06/2019, C79000-G8976-C551-02
CAUTION
