3 Installation, commissioning, safety

3.1 General information

The devices can only be used in conjunction with the Locating Manager.
•
Correct setup, installation and use of the software and clients of the localization system are
•
described in the corresponding manuals.

3.2 Mounting

Before installing the device, read carefully through all points in "3. Installation, commissioning,
•
safety" to guarantee proper installation and operation.
The device is intended for fixed installation on walls or ceilings.
•
Installation of the device must be performed by appropriately qualified and trained specialist
•
personnel according to the installation instructions.
The notes on the environmental conditions must be observed during installation and operation
•
of the devices.
Ensure that all screws are securely and firmly screwed into the wall and can support the weight
•
of the device and wiring.
The ambient temperature of the devices must not exceed 60 °C. Avoid installation locations
•
exposed to direct sunlight.
The devices must be installed according to the currently applicable BG regulations "Electrical
•
Installation and Equipment" (BGV A3). The devices must be installed in such a way that they
are always accessible (opening the enclosure cover) so that subsequent maintenance work can
be performed.

3.3 Connection of the cable

When connecting the cables, make sure that the twist-lock plug/lock engages correctly to
•
reliably prevent the ingress of moisture.
Before commissioning the device, check whether the cabling has been correctly performed.
•
Only the wiring described in the manual, supplied with the device or accordingly specified
•
should be used. Siemens AG accepts no liability for damage or impairment of functionality
resulting from the use of other cables.
Note
If the plug connections are not used, they must be closed with the prescribed cover caps.
These are installed on the device.
