3.3.1 Supply voltage

When the supply voltage is connected to the power plug, all LEDs flash for a moment. The
•
power LED is on when voltage is applied (see status of LEDs 2.2.1).
The device can be supplied with power via the Ethernet cable. In this case, the power plug
•
should be tightly sealed to prevent moisture from penetrating.
Do not supply the device with power via the power input and PoE at the same time.
•
Check whether the rated voltage of the power supply corresponds to the values in the section
•
"Technical specifications" (see 5).
CAUTION
The power supply of the device must not exceed the following values:
U < 30 V; I < 3.3 A; P < 100 W

3.3.2 Ethernet (only with gateway)

When installing and connecting the Ethernet connection, the applicable general conditions and
•
their legal basis must be observed.
The Ethernet connection is connected to the Ethernet socket of the device. The cable must be
•
connected to the RJ45 plug before connection to the socket.
For the power supply of the device with PoE (Power over Ethernet), a corresponding
•
infrastructure such as PoE injector or PoE switch is required.

3.4 Operation

Due to its design, the device is not intended for use in hazardous zones.
•
The proper operation of the system according to EN 60950-1 is only guaranteed when the
•
enclosure cover is mounted (cooling, fire protection, radio interference suppression).
In an emergency (e.g. damaged enclosure, ingress of liquid or foreign objects), immediately
•
disconnect power to the equipment.
An anchor is ready for operation when the upper green LED lights up permanently. The other
•
two LEDs play no role in operational readiness.
A gateway is ready for operation when both the upper green LED and the lower blue LED light
•
up permanently. The third (middle) LED plays no role in operational readiness.
