Optional - Telescopic Arm
Operating the Telescopic Arm
Use the electric switch to adjust the length of the extending telescopic dipper arm to
suit working conditions and use dipper ram to vary reach as required.
Over frequent use of telescopic arm will cause premature wear of adjustable pads.
Transport of the Telescopic arm
Always fully retract before folding machine arms into transport position.
Excel 606, 686, 726 & 836
Spearhead
Description of the

Telescopic arm

Telescopic extending arm provides
extra reach, particularly useful for
deep ditches, banks and for reaching
high hedges.
45
