Grass Cutting

Recommended for grass cutting
•
1.2 rotor
•
Rear roller
•
Cowl wear plate
•
"C" flails or "Back to Back" flails
Note: The 1.5m head is not recommended for grass cutting.
Excel 606, 686, 726 & 836
•
Optional - "Boot" flails
•
Front and rear flap
•
Head float and Angle Float
•
Auto-pilot
Cutting Height Adjustment
Grass cutting
Set rear roller down to control cutting height.
Have rubber flap fitted to the front and rear
of head and close down the adjustable front
hood to reduce flying debris to a minimum.
Warning
Never remove front cowl.
Do not operate without front and rear flap.
Do not verge mow without a rear roller.
Do not verge mow with rear roller set too
high; remember the rear roller is used to
control the cutting height.
Optional belt drive rotor
Use larger pulley on rotor shaft for reduced
speed 2500 rpm.
