Spearhead
Optional – Angle float
Head angle float
This option allows the flail head to follow contours of the ground without having to
constantly control the angle of the head.
The centre of balance is the best mounting point for the head if angle float is to be
used properly.
Operating the head angle float
Place flail head on the ground and switch on angle float control, this opens the head
ram to tank, and allows the ram to float in or out, maintaining full contact with the
ground automatically.
To regain manual control switch off.
Warning
Do not fold the machine up for transport before turning off the angle float.
Excel 606, 686, 726 & 836 33
