Spearhead Excel 606 Handbook page 16

Spearhead
Attaching your machine to the tractor – using 3
point linkage
Remove slew-locking pin
16
Adjust top link
19. Remove locking pin from slew post before
operating the machine, and slew forward
20. Operate the main arm to bring the frame
horizontal by lowering the head weight to the
ground.
21. Adjust top link length until the main frame is
vertical.
Excel 606, 686, 726 & 836
