Auto pilot switch alignment
Alternative settings
Move cams apart to increase amount
of weight carried on the rear roller,
there by reducing the sensitivity of
the auto-pilot
If the cams are to close together the
switches will constantly be altering
the main arm height causing
unnecessary wear and strain on the
hydraulics
Note
The basic factory setting for the spring length is 200mm
40
Warning
If the working range is altered the
spring length on the damper may
need adjusting to compensate.
Bend lever arm of switch to
align with the middle of each
cam, ensure they don't
overlap onto the adjacent
cam.
