Fluid - IKA ICC control Manual

• Fluid (Standard information for IKA
®
IKA Operating temperature
Designation
CF.EG28.N10.80.8
CF.EG39.N20.80.16
CF.EG44.N25.80.19
CF.EG48.N30.80.22
UF.Si.N30.150.10LV
HF.Si.20.200.50
HF.Si.20.250.50A
H O (Water)
2
Customized 1
Customized 2
Check the suitability of the fluid according to your application.
Nomenclature for IKA
CF.EG28.N10.80.8 --
(1) Classification:
HF: Heating Fluid
CF: Cooling Fluid
UF: Universal Fluid
(2) Chemical composition:
Si: Silicone oil
EG: Ethylene Glycol
(3) Temperature range: (Minimum temperature. Maximum temperature)
N: Negative Temperature
(4) Viscosiy:
Viscosiy at 25 °C for Heating Fluid (HF)
Viscosity at -20 °C for Cooling Fluid (CF)
Viscosity at 25 °C for Universal Fluid (UF)
Dynamic viscosity [mPa•s] is a product of kinematic viscosity [mm²/s] and density [kg/m³] of the fluid divided by 1000.
(5) Additional information:
A: Oil Additives
LV: Low Viscosity
Note: for open bath application!
Note: Tap water may be unsuitable for operation because the calcium carbonate content may cause calcification.
High purity water (from icon exchangers) and distilled or bi-distilled water are unsuitable for operation due to corrosive
properties of these media. High purity water and distillates are suitable as a medium after adding 0.1 g soda (Na
sodium carbonate) per liter of water.
Note: The limits can be adjusted according to the fluid used.
® fluid):
range for open bath
application
(°C)
-10 ... 80
-20 ... 80
-25 ... 80
-30 ... 80
-30 ... 130
20 ... 200
20 ... 200
5 ... 95
®

fluid:

(5) Addition information
(4) Kinematic viscosity (8 mm²/s)
(3) Temperature range (- 10–80 °C)
(2) Chemical composition (Ethylene Glycol 28 %)
(1) Classification (Cooling fluid)
Operating temperature
range for closed bath
applications
(°C)
-10 ... 80
-20 ... 80
-25 ... 80
-30 ... 80
-30 ... 150
20 ... 200
20 ... 250
5 ... 95
Safety temperature
(°C)
90
90
90
90
145
255
255
-
Flash point
(°C)
115
115
115
115
>170
>280
>280
-
CO ,
2 3
8
