PC 1.1 Cable:
This cable is required to connect RS 232 port (10) to a PC.
1
6
2
7
3
8
4
9
5
1
RxD 2
TxD 3
4
GND 5
6
RTS 7
CTS 8
Fig. 12
9
USB 2.0 cable A - Micro B:
This cable is required to connect USB port (11) to a PC.
USB micro B
Fig.13
The device is maintenance-free. It is only subject to the
natural wear and tear of components and their statistical
failure rate.
Cleaning
Use only cleaning agents which have been approved by
® to clean IKA ® device.
IKA
Dirt Cleaning agent
Dye isopropyl alcohol
Construction material water containing tenside/isopropyl alcohol
Cosmetics water containing tenside/isopropyl alcohol
Foodstuffs water containing tenside
Fuel water containing tenside
For materials which are not listed, please request in-
formation from IKA ®
Wear protective gloves while cleaning the device.
Electrical device may not be placed in the cleansing agent for
the purpose of cleaning.
Do not allow moisture to get into the device when cleaning.
Before performing a non-recommended method of clean-
ing or decontamination, the user must ascertain with IKA
that this method will not damage the device.

Maintenance and cleaning

Disconnect main plug prior to
cleaning!
application support.
Spare parts order
When ordering spare parts, please give:
- Machine type
- Serial number, see type plate
- Item and designation of the spare part,
see www.ika.com, spare parts diagram and spare parts list.
- Software version.
Repair
Please send device for repair only after it has been
cleaned and is free from any materials which may
constitute a health hazard.
For this you should request the "Decontamination Cer-
tificate" from IKA
from the IKA ® website www.ika.com.
Return the device in its original packaging. Storage packag-
ing is not sufficient. Please also use suitable transport pack-
aging.
®
9
8
7
6
1
2 RxD
3 TxD
PC
4
5 GND
6
7 RTS
8 CTS
9
® , or use the download printout of it
5
4
3
2
1
USB A
