In accordance with IKA ® warranty conditions, the war-
ranty period is 24 months. For claims under the warranty
please contact your local dealer. You may also send the
machine direct to our factory, enclosing the delivery in-
voice and giving reasons for the claim. You will be liable
for freight costs.
Pump performance curve measured with water:
(Measurements done according DIN 12876-2 with water at 20°C; pump in a closed-loop circuit).
300
200
100
0
-100
-200
-300
0 5
Q [l/min]
Fig. 14

Warranty

Pump performance curve

10 15 20
The warranty does not cover worn out parts, nor does it
apply to faults resulting from improper use, insufficient
care or maintenance not carried out in accordance with
the instructions in this operating manual.
3200 rpm
2000 rpm
1000 rpm
22
