Commissioning - IKA ICC control Manual

Check whether the voltage given on the type plate cor-
responds to the available mains voltage.
The socket used must be earthed
(fitted with earth contact).
If these conditions have been met, the machine is ready
for operation when the mains plug is plugged in.
If these conditions are not met, safe operation is not guar-
anteed and the machine could be damaged.
Observe the ambient conditions (temperature, humidity,
etc.) listed under "Technical Data".
After switch on the mains switch (2) at the back of the de-
vice or pressing the power key (A), the screen displays the
device designation and the software version after a beep.
®
IKA
Circulator
ICC control
Version 1.2.008
Fig. 4
After several seconds, screen display the information of
device.
Information
Internal Max:
Internal Min:
External Max:
External Min:
Fluid:
Fig. 5

Commissioning

95 °C
5 °C
95 °C
5 °C
H O (Water)
2
Then the working screen in standby status appears and
the device is ready for operation.
0.00
int °C
ext °C
int 5.00
set °C
Fig. 6
Change the temperature setting with "Temp (+)" button
(E) or "Temp (-)" button (F).
Change the pump speed setting with "Pump (+)" button
(H) or "Pump (-)" button (I).
In standby status, activate the heating function by press-
ing the "Temp" button (D). The device start heating func-
tion, meanwhile the pump start to run.
In working status, stop the pump function by pressing the
"OK/Pump" button (G). The heating function and pump
stops.
In standby status, press the "OK/Pump" button (G) to
start the pump function. The heating function will not be
activated.
In running status, press the "Temp" button (D) to stop the
heating function, the pump keep running.
The control elements of the device allow to be locked
by pressing the key button (O), so no accidental changes
during operation are possible (key symbol appears in the
display) .
By pressing the key button (O) again, the controls are re-
leased (key symbol disappears from the display).
A
Safe Temp °C
1000
Pump rpm
10
