OPERATOR'S MANUAL
58 / KEYBOARD PROGRAMMING
Figure 37
Liquid Application Rates Setup (Step Method)
– MAX APP (Step Method) – Defines the maximum APR limit for the
product.
– RATE 1 through RATE 10 (Rate Method) – Defines up to ten
individual application pre-wet rates (Gallons/Ton).
– BLAST RATE (Step or Rate Method) – Defines a higher than
normal, spot-application rate applied when the red BLAST button is
pressed.
– CHNL LBL (Channel Label) (Step or Rate Method) – Any product
material name of up to nine (9) characters can be keyed in.
Pressing the Enter key stores the name for display on all granular
screens including the Operate screen wherever that material
appears.
Press Function Key F4
(LIQUID APPL RATE)
APPLICATION RATE
SELECT A MENU ITEM
1 LIQUID 1 ENABLED
2 LIQUID 2 DISABLED
3 LIQUID 3 DISABLED
4 LIQUID 4 DISABLED
LIQUID 1 APP RATES
ENABLE YES
STEP METHD YES
APP START 5.0 GAL / TON
IC / DC STP 1.0 GAL / TON
MIN APP 0.0 GAL / TON
MAX APP 10.0 GAL / TON
BLST RATE 10.0 GAL / TON
CHNL LBL LIQUID 1
®
