OPERATOR'S MANUAL
20 / START-UP AND FAMILIARIZATION
Substituting Manual Speed for Standard Speed Sensor
If the ground speed signal is lost, the system ceases to function. A lost
signal can occur due to a loss of a sensor, cabling problems, etc. An
artificial ground speed signal can be substituted to continue limited
operation. The fixed ground speed must be previously programmed and
then can be selected from the Material/Manual Speed Select screen (refer
to Figure 11).
1. Stop the vehicle and turn the Master Switch OFF. After beep, press
and release the Console button on the Operate Screen until the
Material Select screen displays.
2. Press the Blast button to change the selection as prompted at the
bottom of the screen. MANUAL ON will display. As the Blast button is
pressed, NO changes to YES. Releasing the button reverts to the
Operate screen. The ground speed window at display bottom now
reads MANUAL with a speed that has been programmed.
3. Continue spreading material, maintaining displayed speed as closely
as possible, to ensure accurate application. The system spreads
material but no accumulators are updated since system accuracy
cannot be assured. The related sensor and harness should be
inspected and repaired as soon as possible to restore normal
operation.
Returning to the Operate Screen
1. To cycle back to the Operate screen, press the Console button three
times, waiting for the beep before releasing. The Operate screen will
show the material name(s) selected along with the correct
(programmed) target APR.

ACCESSING THE CURRENT TOTALS SCREEN

If Manual Speed operation has been selected, this must first be de-selected
before the Current Totals screen can be cleared.
1. From the Operate screen, press and release the Console button after
the beep until the Current Totals screen displays (refer to Figure 12).
The Master Switch must be in the OFF position before the Current
Totals screen appears showing totals accumulated for the current
product selected.To see other totals, return to the Material/Manual
Select screen and select those products.
®
Control Point
11001-1489-201702 Rev B
