STEVAL-SMARTAG1 evaluation board - Hardware Overview
STEVAL-SMARTAG1 Hardware Description
•
STEVAL-SMARTAG1 is a flexible NFC Tracker evaluation board with sensors includes a comprehensive
software library and a sample application to monitor and log sensor data over NFC from an Android or
iOS device. Ultra-low power sensor node evaluation board mounts an ST25DV NFC Tag, an STM32L0
ARM Cortex M0+, environment sensors (temperature, humidity and pressure) and motion
(accelerometer) sensor.
•
The evaluation board features NFC harvesting to supply power and a battery cradle for a CR2032
battery.
ST25DV64K-JFR6D3
64Kbit dynamic
NFC/RFID tag
STLQ15M18R
Low dropout linear
regulator
ST NFC SensorTag Platform
STM32L031K6U6
ARM Cortes-M0+ 32bit
Microcontroller
LIS2DW12
Ultra–low power 3-axis
digital Accelerometer
LPS22HB
Low-power digital sensor for
ambient Pressure
HTS221
Capacitive digital sensor for
Relative Humidity and Temperature
