Summary of Contents for Blizzard Lighting G-Mix 200

  • Page 1: G-Mix™ 200 Moving Head

    Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2019...
  • Page 2: Table Of Contents

    Gobo Replacement Static Gobos Rotating Gobos 5. Appendix Keeping Your G-Mix™ 200 As Good As New Returns (Gasp!) Shipping Issues Tech Specs Troubleshooting Dimensional Drawings Photometric Data Page 2 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 3: Getting Started

    Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time.
  • Page 4: Safety Instructions (Don't Stick Your Hand In The Toaster!)

    Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www. blizzardlighting.com/support. Page 4 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 5: Meet The G-Mix™ 200

    Zoom Fine (0% <--> 100%) Frost (0% <--> 100%) Prism 1 (3-facet) Reset Prism 1 Rotate Prism 2 (8-facet) Prism 2 Rotate Iris Frost (0% <--> 100%) Reset Page 5 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 6: G-Mix™ 200 Pin-Up Picture

    Head/Arms Light Engine Display Carry Control Handle Buttons Figure 2: Rear Connections Fuse 3/5-Pin Holder DMX Input Power Power Power 3/5-Pin Switch Input Output DMX Output Page 6 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 7: Setup

    Maximum capacitance between conductors – 30 pF/ft. Maximum capacitance between conductor & shield – 55 pF/ft. Maximum resistance of 20 ohms / 1000 ft. Nominal impedance 100 – 140 ohms Page 7 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 8: Cable Connectors

    Step 3: Connect other fixtures in the chain from output to input as above. Place a DMX terminator on the output of the final fixture to ensure best communication. Page 8 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 9: Fixture Linking (Master/Slave Mode)

    • Safety cables MUST ALWAYS be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Page 9 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 10: Mounting Points

    Please be aware, you should have a qualified electrician performing all of your electrical connection needs. Be sure to complete all rigging and installation procedures before connecting the main power cord to the appropriate wall outlet. Page 10 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 11: Clamp Mounting

    Be sure to only use the designated rigging point found on the underside of the base assembly for the safety cable. Page 11 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 12: Operating Adjustments

    Press the <OK> button to enable a menu option. To return to the previous option or menu without chang- ing the value, press the <MENU> button. Page 12 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 13: Control Panel Menu Structure

    Zoom 0-255 Run Mode Stop Auto program 1 Auto program 2 Auto program 3 System Language Chinese English Backlight setting Auto Keep on Display Normal Invert Page 13 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 14: Dmx Values In-Depth

    150 <-> 151 Stop 152 <-> 199 Clockwise Rotation (fast <-> slow) 200 <-> 201 Stop 202 <-> 253 Counter-Clockwise Rotation (slow <-> fast) Stop 254 <-> 255 Page 14 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 15 Complete Reset 128 <-> 159 Exp-Curve 160 <-> 191 Linear 192 <-> 223 Log-Curve 224 <-> 255 S-Curve Color Wheel 1 Color Wheel 2 Color Wheel 3 Page 15 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 16: Gobo Replacement

    4) Remove the old gobo, insert the new gobo, and replace in the reverse steps of removal. Gobo holder Gobo Tension ring Rotating Gobos Static Gobos Page 16 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 17: Appendix

    Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 17 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 18: Tech Specs

    Make sure all connectors are seated properly and securely. ing / Responding Use Only DMX Cables. Erratically Install a Terminator. Check all cables for defects. Reset fixture(s). Page 18 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
  • Page 19: Dimensional Drawings

    Luminous Intensity: Beam 3m lux 3m fc 5m lux 5m fc 10m lux 10m fc 5° 122,613 11,391.1 48,988 4,551.2 11,200 1,040.6 42° 2,472 229.7 78.9 22.7 Page 19 G-Mix™ 200 User Manual - Rev. C (c) 2019 Blizzard Lighting, LLC...
