2.4 Control Panel

Fax Monitor
Memory
Reference
Tone/+
Report
Delayed
Space
Transmission
Book Sending Delete
Clear
[22]
[1] Additional Functions Key
[2] LCD
[3] Collate Key
[4] 2 on 1 Key
[5] Copy Key *1
[6] Fax Key *1
[7] In Use/Memory Lamp
[8] Alarm Lamp
[9] Energy Saver Key
[10] Stop/Reset Key
[11] Start Key
[12] # Key
*1: Only for the iR1270F/1570F model.
[1] [2]
Function
R
Redial / Pause
D.T.
Coded Dial
Directory
Receive Mode
Fax Resolution
[20] [19] [18]
[21]
*1
[3] [4] [5] [6]
ABC
GHI JKL
OK
PQRS TUV
[17] [16] [15] [14]
[13]
F2-4
[13] Keypad
[14] * Key
[15] Right Arrow/+ Key
[16] Image Quality Key
[17] Paper Select Key
[18] OK Key
[19] Exposure Key
[20] Enlarge/Reduce Key
[21] Left Arrow/- Key
[22] One-Touch/Fax Function Key (after a press on
the Function key)
