Advantech AIIS-1750 Startup Manual

AIIS-1750
32-Channel Isolated Digital I/O Card
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
• 1 x AIIS-1750 card
• 1 x Quick start user manual
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in
a residential area is likely to cause interference. In such
cases, users are required to correct the interference at their
own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This type
of cable is available from Advantech. Please contact your
local supplier for ordering information.
Overview
The AIIS-1750 offers isolated digital input and output chan-
nels with up to 2,500 V
DC
ideal for industrial applications that require high-voltage
isolation. Additionally, the AIIS-1750 features a digital filter
on each channel.
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
For technical support and services, visit
https://www.advantech.com/support/
This startup manual is for AIIS-1750.
Part No. 2001175001
Printed in Taiwan
isolation protection, making them
Edition 2
October 2018
Specifications
Isolated Digital Input
Number of Channels
Optical Isolation
Opto-Isolator Response Time
Overvoltage Protection
Input Voltage
Isolated Digital Output
Number of Channels
Optical Isolation
Output Voltage Open Collector
Sink/Source Current
General
I/O Connector Type 37-pin box header
Dimensions 96 x 102 mm (3.8 x 4.0 in)
Power Consumption Typical
Power Consumption Max..
Operating
Temperature
Storage
5 ~ 95% RH non-condensing
Relative Humidity
(refer to IEC 60068-2-3)
Certification CE/FCC
16 (bi-directional)
2,500 V
DC
100 μs
70 V
DC
VIH (max.) 50 V
VIH (min.) 5 V
DC
VIL (max.) 2 V
DC
16
2,500 V
DC
5 ~ 40 V
DC
500 mA max./channel
+3.3 V @ 280 mA
+12 V @ 330 mA max.
+3.3 V @ 420 mA
+12 V @ 400 mA
0 ~ 50 °C (32~ 122 °F )
(refer to IEC 60068)
-20 ~ 70 °C (-4 ~ 158 °F)
AIIS-1750 Startup Manual 1
DC
