Advantech AIIS-E730 Startup Manual

AIIS-E730
32-channel Isolated Digital I/O Card
Packing List
Before installation, please make sure that you have received
the following:
• AIIS-E730 card
• Quick Start User Manual
If anything is missing or damaged, contact your distributor or
sales representative immediately.
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause interference in which case the user is
required to correct interference at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This kind
of cable is available from Advantech. Please contact your
local supplier for ordering information.
Overview
The AIIS-E730 offers isolated digital input channels as well
as isolated digital output channels with isolation protec-
tion up to 2,500 V , which makes them ideal for industrial
DC
applications where high-voltage isolation is required. The
AIIS-E730 also features a Digital filter on each channel.
Notes
For more information on this and other Advantech products,
please visit our websites at:
http://www.advantech.com
For technical support and service:
http://www.advantech.com/support/
This startup manual is for AIIS-E730.
Part No: 2003F73000
1 Startup Manual
1st Edition
January 2016
Specifications
Isolated Digital Input
Number of Channel
Optical Isolation
Opto-isolator response time 25 μs
Over-voltage Protect
Input Voltage
Input Current
Digital Output
Number of Channels
Optical Isolation
Output Voltage
Sink/Source Current
General
I/O Connector Type
37-pin box header
Dimensions 96 mm x 102 mm (3.8" x 4.0")
Typical
Power Consumption
Max
Operation 0 ~ 50°C (32~ 122 °F )
Temperature
Storage
5 ~ 95% RH non-condensing
Relative Humidity
(refer to IEC 60068-2-3)
Certification CE/FCC
16 (bi-directional)
2,500 V
DC
70 V
DC
VIH (max.) 30 V
DC
VIH (min.) 3 V
DC
VIL (max.) 1 V
DC
3 V 0.5 mA (typical)
DC
12 V 3.1 mA (typical)
DC
24 V 6.6 mA (typical)
DC
30 V 9.73 mA (typical)
DC
16
2,500 V
DC
Open collector 5 to 40 V
DC
500 mA max./channel
+3.3 V @ 265 mA
+12 V @ 40 mA
+3.3 V @ 475 mA
+12 V @ 75 mA
(refer to IEC 68 -2 - 1 ,2)
-20 ~ +70°C (-4 ~158°F)
