15 MENU The Settings page opens.
16 GAIN/TX Short press: Gain/Sea/Rain of Radar and Gain of Fish Finder are adjusted in combination with
the RotoKey™.
Long press: Radar or Fish Finder is set to TX or STBY.
17 EVENT An event is entered to the own ship position.

2.5. Cross Cursor

While the cursor is operated with the joystick, a cross cursor is shown on the screen.
Cursor Speed Adjustment
The cursor speed is adjustable in the menu.
[Menu] (TZT9/14/BB) / [Settings] (TZTL12F/15F) –
[General] – [Cross Cursor Speed]

2.6. General Limitations and Notes

(1) Limitation in Drag by Joystick (MCU-002 and MCU-004)
The joystick has NO "drag" function. The guard zone setting of Radar,
which requires to be adjusted by drag, will not be available with the
MCU-004 joystick. This operation should be made by touch operations or
with a generic mouse/trackball unit.
(2) Limitation in 3D Mode – Pan/Tilt (MCU-002 and MCU-004)
You can turn the screen mode into the 3D mode by selecting [3D Mode]
from the contextual menu. However, you cannot pan/tilt the chart
with the MCU-002/4, because sliding the screen with two fingers is the
only way to pan/tilt it. The 3D chart will always be at the default angle as
shown at right. Or if you have paned/tilted the chart with two fingers
before, the screen will be in the previously set angle.
Cross Cursor on Screen
8
