Digital Vision Network
5000 Rackmount Series
Quick Installation Guide
February, 2009
24-10129-4 Revision E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rackmount 5000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls Rackmount 5000 Series

Summary of Contents for Johnson Controls Rackmount 5000 Series

  • Page 1 Digital Vision Network 5000 Rackmount Series Quick Installation Guide February, 2009 24-10129-4 Revision E...

  • Page 2: Federal Communication Commission Notice

    All Rights Reserved (805) 522-5555 www.johnsoncontrols.com No part of this document may be reproduced without the prior permission of Johnson Controls, Inc. These instructions are supplemental. Often they are supplemental to other manufacturer’s documentation. Never discard other manufacturer’s documentation. Publications from Johnson Controls, Inc.
  • Page 3  RAID configuration recommendation (see page 35)  Quick start checklist (see page 37)  ACKAGE ONTENTS Thank you for choosing the Johnson Controls DVN 5000 Series server. DVN 5000 SERIES SERVER INSTALLATION CD: TRAINING CD • Software • Manuals...

  • Page 4: Manual Conventions

    UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 5: Safety Information

    RAID drives and system drive into the unit’s drive bay (front of unit), unless your DVN 5000 was shipped with the drives already inserted into the drive bay. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 6 4. Press each drive into its designated slot until it clicks and the handle is held behind the release button. (front view) 0 1 2 3 (front view) 0 1 2 3 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 7: Connecting The Power

    CAUTION the unit back to Johnson Controls for repair for which you will not receive credit. See “Inserting the RAID Drives and System Drive in the Drive Bay” on page 3.
  • Page 8 DVN 5000 during the unit’s warranty period will tear the warranty seal and void the unit’s warranty. See also page 9. (front view) Soft power switch (front view) Soft power switch 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 9: Uninterruptible Power Supply (Ups)

    DVN 5000 Rackmount Series Server Quick Installation Guide Uninterruptible Power Supply (UPS) Johnson Controls strongly recommends providing power to the DVN 5000 unit via a listed UPS for temporary, backup power in the event of a power failure. Recommended Manufacturer: APC®...

  • Page 10: Lithium Battery Replacement

    Except for the battery, there are no user serviceable parts inside the unit. Refer to your dealer for any service needs. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 11: Warranty Information

    DVN model, manufacturing date code, country where the unit was assembled, and a warning statement. This sticker must be affixed to the unit and intact to receive warranty service on a defective DVN unit at a Johnson Controls authorized repair facility.
  • Page 12 Quick Installation Guide DVN 5000 Rackmount Series Server DVN 5000 Real-Time or Multiplexed Connections 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 13 DVN 5000 Rackmount Series Server Quick Installation Guide DVN 5000X Real-Time (for Network Cameras) Connections 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 14: Alarm Inputs

    Not Used Ground Alarm16 Alarm15 Alarm14 Input Example N/O shown (may also be N/C, depending on the software configuration) Customer Supplied Ground 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 15: Auxiliary Outputs

    DVN 5000 Series Software Installation and Configuration Manual. Output13 Output12 Output11 Output10 Output9 Output8 Output7 Output6 Output5 Output4 Output3 Output2 Output1 Not Used Ground Output16 Output15 Output14 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 16: Output Example

    DVN 5000 model. DVN Model Mono Channels Stereo Channels DVN5004-RT DVN5008-RT DVN5016-RT DVN5016X DVN5016R DVN5016M DVN5008R DVN5008M DVN5032X DVN5032R DVN5032M 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 17: Audio Specifications

    Enable a microphone in the DVN software as the left channel for each audio input. Refer to the DVN 5000 Series Software Installation and Configuration Manual for assistance. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 18 OK button 2. On the Software License Agreement screen, read the license conditions and click Accept. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 19 For security reasons, we highly recommend that you add the administrator’s password as soon as you access the RemoteControl Main screen. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 20: To Configure Network Settings

    Setup. 2. On the Setup screen, click System. 3. On the System Configuration screen, click Network Cards next to Incoming Connections. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 21: To Set The Date And Time

    To manually set the DVN 5000 server’s clock, set the hour, date, and time zone and click Submit. You will be logged out. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 22 Camera drop-down list. Live video footage from that camera appears in the Video window. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 23 16. Repeat steps 3-15 for each connected camera. 17. Click Apply. 18. On the Cameras Configuration – Standard screen, click OK. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 24 Controls, select DVN 5000, DVN 3000, or DVN 100. For the AXIS, Panasonic, or Sony device class, select Fixed Camera or PTZ Camera. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 25 12. (Optional) To configure the DVN 100-NET encoder or network camera (if applicable), click Open. You may be required to enter a user name and password to modify the device’s settings. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 26 Before configuring the record scheduler, if you need to configure any of the following, do so before proceeding: Camera configuration  PTZ dome presets  PTZ dome targets tours  24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 27 The Boosted check box will be disabled. By default, the connected cameras are set to record for 24 hours and the Prime and Alarm sectors are enabled. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 28 To assign a preset, select the Preset radio button and select the preset  from the drop-down list. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 29 14. From the Encoder Id drop-down list, select the encoder that will be used to record in the currently selected camera sector. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 30 21. On the Record Scheduler screen, click OK. 22. On the Setup screen, click OK.  To set the administrator’s password: 1. On the Setup screen, click Users. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 31 3. Edit the password and click OK. The OK button 4. On the Users Profile page, click to save your changes. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 32 1. On the Setup screen, click Users. 2. On the Users Configuration screen, click Add. On the User Template window, click Ok. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 33 2. In the Address bar, enter the IP address of the DVN 5000 Series server to which you want to connect (for example, http://123.456.7.89). Click Go. The VisionWeb Login page appears. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 34: Troubleshooting

    Verify that the ON/OFF switch on the back of the unit is set to  Verify the power cord is plugged into a proper 120/220 VAC  power outlet. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 35 A 75 ohm terminator on the Loop output will clean up any improperly terminated coax lines. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 36: Changing Thes

    Shutdown” feature. This feature erases all customer settings and requires an Authorization key that must be obtained from Johnson CAUTION Controls. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 37: Raid Configuration

    3. Obtain a valid authorization number from Johnson Controls. To obtain the maintenance code, contact the Johnson Controls Product Sales Team at 1-800-ASK-JNSN (1-800-275-5676) for 24-hour assistance in the USA, Technical Support at 805-582-3117 (menu option 5) in the USA, or one...
  • Page 38 3. In the Alarm drop-down list, select an alarm number you wish to assign to the Broken raid disks detected alarm. If no alarms have been enabled, select Alarm 17. 4. Select the Enabled check box. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 39 DVN 5000 up and running. Detailed configuration instructions and additional features are covered elsewhere in this document and in the DVN 5000 Series Software Installation and Configuration Manual (24-10248-5). 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.

  • Page 40: Hardware Installation Checklist

    If using an Uninterruptible Power Supply (UPS), refer to the device’s user documentation for proper connections to and from the device. 24-10129-4 Rev. E This document contains confidential and proprietary information of Johnson Controls, Inc. © 2009 Johnson Controls, Inc.
  • Page 41 CAUTION unit back to Johnson Controls for repair for which you will not receive credit.  Verify that the power switch on the back of the unit is switched on.
